EMC Hycal Limited products

The Hycal Mini Mk3 portable analyser provides rapid, accurate measurement of hydrogen dissolved in molten aluminium and its alloys.

Probe longevity: 100 measurements typical, 20 hours continuous immersion. Response time: 5 minutes to stable result, response time less than 2 seconds. Footprint: approx. 1/2 volume, approx. 1/2 weight. Operating expense: 3x lower running cost, reduced degassing cost.

Probe longevity: 100 measurements typical, 20 hours continuous immersion. Response time: 5 minutes to stable result, response time less than 2 seconds. Operating expense: 3x lower running cost, reduced degassing cost. Gateway: Profinet, EtherNet/IP.

Probe longevity: 100 measurements typical, 20 hours continuous immersion. Response time: 5 minutes to stable result, response time less than 2 seconds. Operating expense: 3 x lower running cost, reduced degassing cost. Capital expenditure: Less than 50% CapEx, PLC not included.

Probe longevity: 100 measurements typical, 20 hours continuous immersion. Response time: 5 minutes to stable result, response time less than 2 seconds. Probes x 2: Measure before and after degasser, Permanently mounted. Station x 1: Cables route to same panel, 2 Hycals in 1 device.

The Hycal Mini analyser provides rapid, accurate measurement of hydrogen dissolved in molten aluminium and its alloys.

The Heart of Our Technology: At the core of our cutting-edge technology lies the remarkable Hycal sensor. This innovative sensor boasts a patented solid-state reference, setting it apart from traditional technologies. The Hycal sensor can measure hydrogen without the need for an external hydrogen reference.

Stainless steel double-lock conduit. 3 x K-type TC conductors. 3 x EEPROM conductors for digital comms. 4 x conductors for analog probe signals. PTFE fluidic connection for purge  gas. 2 x latching / push-pull 10-pin connectors. Rated to 200 deg C.
