G.E.T. Industries Inc. products
Open Channel Horizontal Flow
Grind Hog - Model 10T/S - Comminutors
There will be furnished one (1) only Grind Hog Model 10T/S Comminutor as manufactured by G.E.T. Industries, Inc. Rotation shall be in a clockwise direction.
Grind Hog - Model 16A T/S - Comminutors
Grind Hog Model 16A T/S comminutors feature rugged cast-iron construction with cutting bar elements of high quality tool steel, CNC machined and surface ground for precise tolerances. The shredding and screening capability is further enhanced through the use of SM-Cyclo gear reducers offering a 500% overload capacity.
Open Channel Vertical Dicharge
Grind Hog - Model 16B - Comminutors
Grind Hog Model 16B comminutors feature rugged cast-iron construction with cutting bar elements of high quality tool steel, CNC machined and surface ground for precise tolerances. The shredding and screening capability is further enhanced through the use of SM-Cyclo gear reducers offering a 500% overload capacity.
Grind Hog - Model 10L - Open Channel - Vertical Discharge Comminutors
There shall be furnished one (1) one only Grind Hog Model 10L Comminutor as manufactured by G.E.T. Industries Inc. Rotation shall be in a clockwise (standard) / counter-clockwise (optional) direction.
FLanged Mounted
Grind Hog - Model 10A - Flange Mounted Comminutors
There shall be furnished one (1) one only Grind Hog Model 10A Comminutor as manufactured by G.E.T. Industries Inc. with rotation in a counter-clockwise direction.
Grind Hog - Model 7A-6 - Flange Mounted Comminutors
There shall be furnished one (1) one only Grind Hog Model 7A-6 Comminutor as manufactured by G.E.T. Industries Inc. with rotation in a counter-clockwise direction.
Grind Hog - Model 7A-8 - Flange Mounted Comminutors
There shall be furnished one (1) one only Grind Hog Model 7A-8 Comminutor as manufactured by G.E.T. Industries Inc. with rotation in a counter-clockwise direction.
Short Block
Interchangeable - Replacement or stand-by component allows for continuous service in applications with multiple Pumping Stations.MODEL 26AS - (Immersible)
The comminutor shall be designed to handle the flows indicated below, within the head loss noted., , hydraulic capacity 20 MGD (75,700m3/day), , satisfactory operation shall occur under conditions of zero flow, , head loss at peak flow shall not exceed 30 inches (762), , design shall be such that the flow enters the size reduction and screening device horizontally and exits vertically downward to facilitate the flushing of solids.
