Glass Aggregate Systems products

Capacity 10-20 Tons per Hour. Dimensions (Length-Width-Height) 40` x 28` x 17`. Weight 10,000 LBS. Electrical Supply (standard) 480/460/208 VAC. Motors (3) 7.5, (2) 2 HP(3) 3 HP. In-Feed Converyor 24" x 26`. Converyor/Sizing Unit 24" x 20` . Converyor/Trommel 18" x 18`. Trommel 12` x 4` x 8`.

Capacity 3-10 Tons per Hour. Dimensions (Length-Width-Height) 40` x 28` x 17`. Weight 8,500 LBS. Electrical Supply (standard) 480/460/208 VAC. Motors (2) 7.5 HP (2) 2 HP(3) 3 HP. In-Feed Converyor 24" x 26`. Converyor/Sizing Unit 24" x 20`. Converyor/Trommel 18" x 18`. Trommel 12` x 4` x 8`.

Capacity 2 Tons per Hour. Dimensions (Length-Width-Height) 24` x 14` x 12`. Weight 3,500 LBS. Electrical Supply (standard) 480/460/208 VAC. Motors (2) 2 HP (3) 1 HP. In-Feed Converyor 18" x 16`. Out-Take Converyor 18" x 14`. Trommel Integrated.

Capacity 1 Ton per Hour. Dimensions (Length-Width-Height) 19` x 4` x 12`. Weight 2,500 LBS. Electrical Supply (standard) 480/460/208 VAC. Motors (2) 1.5 HP (1) ½ HP (1) 1 HP. In-Feed Converyor 12" x 16`. Trommel Integrated.

Capacity 300-500 Pounds Per Hour. Dimensions (Length-Width-Height) 4` x 2` x 5 1/2`. Weight 625 LBS. Electrical Supply 110/115 VAC, 1-phase, 25 amps. Motors 1.5 HP .

Capacity: 5 Tons per Hour. Dimensions: (Length-Width-Height) 22` x 22` x 13`. Weight: 14,000 LBS. Electrical Supply: (standard) 480/460/208 VAC. Motors: (2) 30 HP (1) 2 HP(2) 3 HP. In-Feed Converyor: 30` x 16`. Converyor/Trommel: 24` x 18`. Trommel: 12` x 4` x 8`.

Capacity: 6 - 10 Tons per Hour. Dimensions: (Length-Width-Height) 30` x 10` x 9`. Weight: 3,000 LBS. Electrical Supply: (standard) 480/460/208 VAC. Motors: (1) 5 HP (2) 2 HP. In-Feed Converyor: 18` x 15`. Out-take Conveyor: 18` x 15`. Beverage container breaker system. Liquid filled glass bottles can be crushed.
