10 products found
Hebei Tobee Pump Co.,Limited products
Slurry Pumps - AHR Rubber Slurry Pump
Tobee - Rubber Slurry Pump
Tobee AHR rubber lined slurry pumps are similar to AH metal lined slurry pump in structure. The main difference between AH and AHR is the material of wetted parts, which are natural rubber, synthetic rubber or other wear-resistant rubbers. AHR rubber lined slurry pumps are more suitable in delivering strong corrosive or abrasive slurries of small particle size without sharp edges.
Tobee - Building Material Industry Slurry Pump
6x4D THR Rubber Slurry Pump is made of natural rubber liners and high chrome impeller that used for pumping silica sands. THR rubber lined slurry pumps are more suitable in delivering strong corrosive or abrasive slurries of small particle size without sharp edges. Material selections are extremely important when dealing with wear issues in heavy-duty slurry pumps. Elastomers are also used for a wide variety of special purposes: resistance to erosion, corrosion, heat and many other desirable physical and chemical properties. Tobee technical engineers have the experience to select the right material for your application. So please contact us to solve your problems. THR series rubber slurry pumps are widely used in Mineral processing, Ball mill discharge, Bottom/fly ash, lime grinding, Coal, Coarse sand, Coarse tailings, Dredging, FGD, Fine tailings, Cyclone feed, Flotation, Heavy media, Minerals concentrate, Mineral sands, Ni acid slurry, Oil sands, Tailings, Phosphoric acid,etc.
Tobee - Iron Ore Concentrate Pump with Rubber Liners
Tobee® 8/6E-AHR slurry pumps are the most comprehensive range of centrifugal slurry pumps for use in mining, chemical and general industry applications. The horizontal slurry pumps are designed for heavy duty applications such as mill discharge, power sector and tailings as well as specialty applications, which are used for continuous pumping of high abrasive, high density slurries. Design Features: √ Heavy duty construction with through-bolt design provides ease of maintenance and minimal downtime √ Ductile iron fully lined casing provides durability, strength, safety, and long service life √ Large diameter, slow turning, high efficiency impellers designed to achieve maximum wear life and low operating costs √ Large, open internal passages designed to reduce internal velocities, maximize wear life and lower operating costs √ Minimal shaft/impeller overhang reduces shaft deflection and increases packing life
Tobee - Mineral Processing Slurry Pump
Tobee® 10x8E-M Medium Duty Slurry Pump is cantilevered, horizontal and centrifugal with double casing structure, It mainly suitable for pumping medium concentration slurries. The 10x8E-M slurry pump applies in coal washer processing, handling with the fine ore and tailings in metal mine, handing combined bottom and fly ash in a thermal power station etc. Tobee® 10/8 E-M Slurry Pumps Applications: Iron Ore Dressing Plant, Copper Concentration Plant, Gold Mine Concentration Plant, Molybdenum Concentration Plant, Potash Fertilizer Plant, Other Mineral Processing Plants, Alumina Industry, Coal Washery, Power Plant, Sand Excavation, Building Material Industry, Chemical Industries, Other industries.
Tobee - Rubber Lined Slurry Pumps Impeller Spare Parts
1.5x1 B-THR Rubber Lined Slurry Pumps, Impeller Spare Parts B1052R55 on 1.5x1 TH Tailing pumps. Tobee® can supply TH slurry pump impeller with kinds of relevant material, such as metal slurry pump impeller, rubber slurry pump impeller, polyurethane slurry pump impeller and ceramic slurry pump impeller. open impeller, closed impeller, and semi-closed impeller
Tobee - Polyurethane Impeller for 1.5/1 Slurry Pump
B1052U38 Slurry Pump Polyurethane Impeller is used on small slurry pump 1.5/1B-AHR. Expand work life 3-5times than normal standard R55 material. Slurry pump impeller is the main component in centrifugal slurry pumps which has vanes to impart and direct the centrifugal force to the slurry. Slurry pump impeller is also the most diverse component in slurry pumps, by changing impeller, the same slurry pump can cover more different duties. Slurry Pump Polyurethane Parts(commonly abbreviated PU) is a unique material that offers the elasticity of rubber combined with the toughness and durability of metal. It allows the engineer to replace rubber, plastic and metal with the ultimate in abrasion resistance and physical properties. Urethane abrasion and tear resistance are much better than rubbers, while offering higher load bearing capacity. Compared to plastics, urethane offer superior impact resistance, while offering excellent wear properties and elastic memory.
Tobee - R26A material Throat Bush wetted part F8083R26A
Tobee® R26A material Throat Bush F8083R26A is one of wetted parts for the 10/8 AH Slurry Pump, It links plate liner and forms a Pump chamber to work with impeller,and Its wear-resistance is very important to pump work-life. Tobee can produce rubber slurry pump throat bush in R26A,R55,S42,S51,S10,S12,S14,S31 etc.based one the degree of corrosion of slurry pump media. These wear parts are very crucial to the service life of slurry pumps, For the long service life of pump parts, the material plays an important role here, Tobee offers rubber slurry pump parts are more suitable for delivering strong corrosive or abrasive slurries of small particle size without sharp edges.
Tobee - 4/3D-AHR Slurry pump with Pulley drive
3inch slurry pumps means the pump with 3inch outlet, and 4inch inlet. including model 4/3C-AH, 4/3C-AHR, 4/3D-AH, 4/3D-AHR. They are widely used on minerals processing. 4x3D-AHR Rubber Lined Slurry Pump is the heavy duty slurry pump handling tough and abrasive duties. Rubber slurry pumps are widely used for continuous pumping highly abrasive/dense slurries in processes from cyclone feed to regrind, mill discharge, flotation, mine drainage, dredging of settling lagoons and pumping of drilling mud and tailings in minerals plants and other industrial applications. Design Features: √ Double casings design centrifugal rubber lined slurry pump, wide passage for solids √ Bearing assembly & frame: Both standard & high capacity types available. √ A large diameter shaft with a short overhang minimizes deflection and vibration. √ Heavy duty roller bearing is housed in a removable bearing cartridge. √ Rubber slurry pump body is fastened with the frame by minimum bolts.
Tobee - 6/4E-AHR Rubber Slurry Pumps with abrasion-resistant liners
Tobee® 6/4E-AHR Rubber Slurry Pumps for Copper Mines, and our slurry pumps are lined with replaceable, abrasion-resistant liners, which are designed specifically for the slurry being pumped, with natural rubber, urethane, high-chrome alloy and many other material options, no slurry is too great a challenge. Tobee® 6x4 E-AH Rubber Lined Slurry Pump Specification: Pump type: Single-Stage Pump Capacity: 144-324 m3/h Head: 12-45 m Speed: 800-1350 r/min Impeller Dia.: 365 mm Matching power: Max.120 kW Seal arrangement: Packing seal, Expeller seal, Mechanical seal Working pressure: Low Pressure Pump Pump Type: Horizontal Slurry Pump Material: R08, R26, R55, S02, S12, S21, S31, S42 etc Warranty: 3 Year (except Wet End Parts) Tobee® 6x4 E-AHR Rubber Lined Slurry Pump Design Features: √ Cylindrical structure of bearing assembly: convenient to adjust the space between impeller and front liner and can be removed completely. √ Interchangeable anti-abrasive wet parts made of high-chrome alloys.
