Long distance pipeline transportation / Crude Oil & Product Oil transportation / Other Liquid Chemical production transportation

Performance Range Capacities: Q ~8000 m³/h   (~88064 gpm)Heads:  H ~1800m (~919 feet). Temperatures:  T ~205℃.
Executive Standard According to API 610 standard.

Horizontal, radically split, single stage or double stage ( specilal condition three stage or four stage ), centerline mounted, between bearing structure. The suction flange and discharge flange are equipped vertically up in the pump casing. Mechanical seal chamber and pump casing are casting together, suitable for all kinds of mechanical seal, and the optional water cooling chamber jacket are casted out of the mechanical seal chamber.  Executive Standard According to API 610 standard.

Flow rate: Q ~800 m3/h (~88064 gpm). Head: H ~ 1200m (~919 feet). Temperature: T -80°C~180°C. Design pressure: P ~15 MPa. Executive Standard According to API 610 standard.

The single-stage double-suction horizontal open design balances the axial force of the pump. The medium-open structure eliminates the need to disassemble the piping system during pump maintenance, and the various bearing structures are designed to meet the needs of different occasions. Executive standard API610 standard.

The TTVC series of vertical bag pumps are multi-stage, radial split and are equipped with a housing. The first stage impeller is generally a suction type impeller. The axial force is absorbed by the radial thrust ball bearing. In the case where the pressure difference is large, the axial force is balanced by the balance drum device. The housing is only subjected to inlet pressure, and the length of the housing and the depth of installation of the pump depend on the NPSH cavitation performance requirements. If the pump is installed on the vessel or connected to the pipe flange, the casing (ie TVC type) may not be installed. The bearing lubrication is lubricated with thin oil and has an independent internal circulation automatic lubrication system. A hydrodynamic radial plain bearing is located at the inlet end of the pump.

The shaft structure is safe and reliable, the rotor parts can be adjusted axially, the rotor parts are supported by multiple points, the operation is reliable, the sliding bearings are externally flushed, and the pump above 80mm has a double volute to balance the radial force. Executive standard API610 standard.

According to the fire pump standard, high-grade corrosion-resistant materials are selected, and the products are stable and reliable. The performance curve is stable, and the head will not plummet when the flow is increased. The control cabinet controlled by PLC realizes the whole-time duty of the unit and has good safety. Motor or diesel engine can be used as the drive machine. The pump speed covers the common speed of motor and diesel engine to meet various requirements of customers.

The single-stage double-suction horizontal open design balances the axial force of the pump. The medium-open structure eliminates the need to disassemble the piping system during pump maintenance, and the various bearing structures are designed to meet the needs of different occasions. Executive standard API610 standard.
