Icar Bazzoli Enzo s.r.l. products

Net load moment: 145 KNm. Rotational torque (net): 32 KNm. Rotation angle: 425°. Maximum reach: 10.4 m. Operating pressure: 240 Bar. Recommended pump flow rate: 1x90 Lt/min, 2x80 Lt/min, LS 1x150 Lt/min. Loader weight (excluding terminal equipment): 2600 kg.

Net load moment: 145 KNm. Rotational torque (net): 32 KNm. Rotation angle: 425°. Maximum reach: 10.4 m. Operating pressure: 240 Bar. Recommended pump flow rate: 1x90 Lt/min, 2x80 Lt/min, LS 1x150 Lt/min. Loader weight (excluding terminal equipment): 2600 kg.

Net load moment: 98 KNm: 127 KNm. Rotational torque (net): 28 KNm: 30 KNm. Rotation angle: 425°: 425°. Maximum reach: 9.50 m: 9.50 m.
Operating pressure: 240 Bar: 240 Bar. Recommended pump flow rate: 1x90 - 2x70 Lt/min: 1x100 - 2x80 Lt/min. Loader weight (excluding
terminal equipment): 2800 kg: 2850 kg.

Net load moment: 98 KNm: 127 KNm. Rotational torque (net): 28 KNm: 30 KNm. Rotation angle: 425°: 425°. Maximum reach: 8.30 m: 8.30 m. Operating pressure: 240 Bar: 220 Bar. Recommended pump flow rate: 1x90 - 2x70 Lt/min: 1x100 - 2x80 Lt/min. Loader weight (excluding
terminal equipment): 2750 kg: 2800 kg.

Net load moment: 101 KNm: 130 KNm. Rotational torque (net): 28 KNm: 30 KNm. Rotation angle: 425°: 425°. Maximum reach: 7.50 m: 7.50 m. Operating pressure: 240 Bar: 240 Bar. Recommended pump flow rate: 1x90 - 2x70 Lt/min: 1x100 - 2x80 Lt/min. Loader weight (excluding terminal equipment): 2700 kg: 2750 kg.

Net load moment: 104 KNm: 140 KNm: 158 KNm. Net rotation torque: 28 KNm: 30 KNm: 32 KNm. Rotation angle: 425°: 425°: 425°. Maximum reach: 10.30 m: 10.30 m: 10.30 m. Operating pressure: 240 Bar: 240 Bar: 260 Bar. Recommended pump flow rate: 1x90 Lt/min, 2x70 Lt/min: 1x100 Lt/min, 2x80 Lt/min: 1x100 Lt/min, 2x80 Lt/min. Loader\Crane weight (excluding terminal equipment): 2400 kg: 2600 kg: 2650 kg.

Net load moment: 140 KNm. Net rotation torque: 30 KNm. Rotation angle: 425°. Maximum reach: 9.40 m. Operating pressure: 240 Bar. Recommended pump flow rate: 1x100 Lt/min, 2x80 Lt/min. Loader\Crane weight (excluding terminal equipment): 2500 kg.

Net load moment: 96 KNm: 138 KNm. Net rotation torque: 28 KNm: 30 KNm. Rotation angle: 425˚: 425˚. Maximum reach: 9.20 m: 9.20 m. Operating pressure: 240 Bar: 240 Bar. Recommended pump flow rate: 1x90 Lt/min, 2x70 Lt/min: 1x100 Lt/min, 2x80 Lt/min. Loader\Crane weight (excluding terminal equipment): 2700 kg: 2800 kg.

Net load moment: 101 KNm: 130 KNm. Net rotation torque: 28 KNm: 30 KNm. Rotation angle: 425˚: 425˚. Maximum reach: 8.30 m: 8.30 m. Operating pressure: 240 Bar: 240 Bar. Recommended pump flow rate: 1x90 Lt/min, 2x70 Lt/min: 1x100 Lt/min, 2x80 Lt/min. Loader\Crane weight (excluding terminal equipment): 2700 kg: 2750 kg.

Net load moment: 105 KNm. Net rotation torque: 28 KNm. Rotation angle: 425˚. Maximum reach: 9.40 m. Operating pressure: 240 Bar. Recommended pump flow rate: 1x90 Lt/min, 2x70 Lt/min. Loader\Crane weight (excluding terminal equipment): 2300 kg.
