Indra S.r.l. products

ASME Class - 150Ib to 2500Ib. API 3000 / 5000 / 10000 / 15000. Size - 1/2" to 8" (FB & RB). Soft Seated & Metal Seated. Lever, Gearbox or Actuated. Temperature range -46°C to +240°C. Special HT versions up to 500°C. Cryogenic versions.

Connections: From 1/2" to 2", Threaded, Flanged, Welded (BW o SW), Hub. Rating: ASME Class - 150Ib to 2500Ib, APl 3000 / 5000 / 10000 / 15000.

Sampling DBB valves are used for sampling - injection purposes and further analysis of the process. The valves are designed both with integral body and sampling probe (not welded). Probe length is defined in accordance to the application requirements and the pipe line diameter. Indra can provide the Wake frequency calculation and the Bending stress calculation to ensure both the correctness of the selected probe length and the valve optimal performance over time.

Connections: From 1/2" to 2", NPT, BSPP, BSPT, BW, SW, Autoclave*. Rating: 6000 / 10000 / 15000* PSI (threaded types), SCH. 40, 80, 160, XXS (BW-SW version). Bonnet: Screwed, O.S. & Y. Bolted, Antitamper, Extended locking device, Cryogenic service.

Connections: Inlet: 1/2"` to 4" flanged, Outlet: threaded & flanged. Rating: ASME Class - 150lb to 2500Ib, APl 3000 / 5000 / 10000 / 15000. Bonnet: Screwed, O.S. & Y. Bolted, Antitamper, Extended optional locking device, Cryogenic service.

Manifold for high safety standards. SIL 4 certified interlock solution. Integral construction. Several DBB lines with a single control element. Suitable for HIPPS systems - High Integrity Pressure Protection System.
