IRIS Instruments products

The Elrec Lite G is a 2-channel hand held induced polarisation (IP) and Resistivity receiver mostly designed for mineral exploration. This low-weight device is particularly suited for sounding and profiling measurements where the operator must move from several hundreds of meters, carrying the receiver.

The Elrec 6 is a 6-channel Induced Polarisation (IP) and Resistivity receiver designed to improve productivity when recording deep profiles and soundings. Beside the classical arithmetic and logarithmic modes, ELREC 6 also offers a Cole-Cole mode and ten fully programmable windows for a higher flexibility in the definition of the IP decay curve. A setup wizard guides the operator through each parameter to ensure the instrument is configured correctly.

The Elrec Pro is a 10 channel Induced Polarisation (IP) and Resistivity receiver designed to improve productivity when recording deep profiles and soundings. Beside the classical arithmetic and logarithmic modes, ELREC Pro also offers a Cole-Cole mode and twenty fully programmable windows for a higher flexibility in the definition of the IP decay curve. A setup wizard guides the operator through each parameter to ensure the instrument is configured correctly. The system includes built-in quality control tools to aid the operator validate measurements during data acquisition, and displays IP decay curves in real time.

The V-FullWaver systems were specifically developed for precise full waveform time domain Induced Polarisation, Resistivity and SP measurements. Each system is fully independent; incorporating its own power source, GPS module and digital memory for up to 3 months continuous recording. The V-FullWaver is a dual channel Induced Polarisation, Resistivity and SP receiver. Continually recording at 10ms sample rate provides a full waveform record. It can be synchronized on the GPS PPS signal, allowing an easy process of the signal. Data on the memory can be downloaded directly on a simple USB stick from all the Fullwavers.

The I-FullWaver systems were specifically developed for precise full waveform time domain induced polarisation, Resistivity and self-potential measurements. Each system is fully independent; incorporating its own power source, GPS module and digital memory for up to 3 months continuous recording. The I-FullWaver sits in series between the injection electrode and transmitter (e.g. TIPIX, VIP) recording the AB injection current to within 3mA. Sampling at up to 100Hz, the GPS PPS is used to synchronise an internal clock in order to accurately time stamps each record within an absolute accuracy of 250us. The I-FullWaver can be used alongside the V-FullWaver or Elrec Induced polarisation receivers.
