Jiangsu Lianming Equipment Technology Co., Ltd. products

Number of Spindles: 1. Wire size MM: 0.2-1.8. Controller: Multi-axis motion control card. Main motor: 1.5KWservo motor. Spreading motor: 400Wservo motor.

Specially designed fixtures, chucks and wire wipers are ground, polished, mirror-plated, etc., so that the enameled wire`s skin is not damaged, and the winding is tight and the wires are neatly arranged. Optional electromagnetic tensioner, the tension can be adjusted directly on the controller. Electronic gratings and machine safety doors can be installed. Can be customized according to customer requirements.

It is suitable for winding coils of automobile water pump motors, computer fan cooling motors, industrial ventilators, drone motors, etc. This machine uses a multi-axis motion controller to control and drive three-axis servo motors and multiple cylinders to perform automatic actions such as winding, arranging, clamping and intermediate taps.

Different wire diameters can be wound around, one side can be wound while the other side can be loaded and unloaded to improve production efficiency. The cable reversing intelligent deceleration, and the rapid cable arrangement has a larger cable torque. Full-screen LCD display, the operation is more convenient and fast. Input and output photoelectric isolation, the chip runs normally and stably. The winding data is automatically saved when the power is turned off, effectively avoiding scrapped coils.

Axis stop accuracy: plus or minus 0.5 degrees. Applicable wire diameter: 0.02mm-0.5mm. Maximum turning diameter: 60mm. maximum width: 80mm.

This model is automatic, Manual operation is also required,and the speed is fast. The advanced LCD + backlight display mode, the operation mode of modern mobile phones, eliminates the shortcomings of digital tubes, such as dizzying fatigue and cumbersome setting operations. The motor directly exits the shaft without loss of transmission power. Zero maintenance, no carbon brushes, electromagnetic brakes, belts and other mechanical wear, we use advanced electronically controlled braking methods.

This model is automatic, Manual operation is also required,and the speed is fast. The advanced LCD + backlight display mode, the operation mode of modern mobile phones, eliminates the shortcomings of digital tubes, such as dizzying fatigue and cumbersome setting operations. The motor directly exits the shaft without loss of transmission power. Zero maintenance, no carbon brushes, electromagnetic brakes, belts and other mechanical wear, we use advanced electronically controlled braking methods.

AC servo motors are used for the main shaft and each dimension, and the running speed and positioning speed of each axis are fast and accurate. The terminal winding can be realized, and the terminal winding can be in both vertical and horizontal directions. Replacement of winding varieties: just call the programmed program in the machine and replace the quick fixture. Thread end treatment method: a: The broken wire is cut by the cylinder; b: The waste wire falls into the waste wire groove. Programming method: LCD touch screen programming, providing human-computer interaction video teaching system to achieve WYSIWYG programming effect. The machine keeps running at all times, reducing product handling opportunities, producing products with good consistency and higher product Q value.

Widely used in medium-sized coils such as rectifiers, solenoid valves, and high-power transformers. You can change the program to achieve multi-function according to your needs. The power supply circuit adopts an improved anti-interference circuit with strong anti-interference ability. The position of the bobbin can be designed with the teaching function, which can assist the setting of the winding point and the width position. 0~999 groups of steps are easy to set. With powerful AC motor and precision stepper motor, it can easily set forward and reverse, cross-slot and flow-dense winding work. Large torque, large displacement, purchase of magnetic damping tension wire rack, the tension is more stable. The maximum wire diameter of 3.0mm can be wound; Lengthening layout can be selected, and the maximum layout width can be 1500mm.
