The lightweight hand sampler DH48 is used for the collection of suspended sediment samples by wading rod suspension. The easy-to-use sampler consists of an epoxy coated, streamlined aluminium casting (weighing approx. 2 kg), which partially encloses the sample container. An intake nozzle extends horizontally from the nose of the sampler body. The axis of the sample container is inclined at an angle to the vertical which permits sampling to within 90 mm of the stream bed.

DH59 is an easy-to-use medium-weight suspended sediment sampler. The sampler consists of an epoxy coated, streamlined bronze casting weighing approx. 10 kg, which partially encloses the sample container. It is equipped with a tail vane assembly to orient the intake nozzle into the approaching flow as the sampler enters the water.

KISTERS’ easy-to-use rising stage sampler RSS is the ideal device for the automatic collection of samples from flashy, intermittent streams at remote or not easily accessible sites, which are visited by personnel at infrequent intervals.

KISTERS’ bed load sampler BLSH is an easy-to-use hand-held sampler for measuring and analysing coarse sand, silt, gravel, rock or other insoluble materials carried by a stream on or immediately above its bed. The bed load samplers are designed for use in natural streams to determine rate of sediment concentration relative to ?ow.

KISTERS’ bed load samplers are designed to sample sand, silt, gravel or rock debris carried by a stream on or immediately above its bed. The BLS30 and BLS48 cable-suspended bed load samplers are used in natural streams for carrying coarse sediments.
