McMillan Company products

The Model 109 Micro FLO-SENSOR will precisely measure flow rates of virtually any fluid, as low as 0.05 mL/minute or as high as 10 mL/minute. Repeatable results are achieved by utilizing a patented thermal mass flow sensor, designed for use with liquid applications. This proven design provides reliable results for extremely low flow rates. Stainless steel tube fittings provide easy connection and connect to all stainless steel wetted parts. This allows the 109 to be used with most fluids, including acids, solvents, and other corrosive chemicals. A pressure rating of 500 psig maximum allows for installation in higher-pressure systems.

McMillan Model U701 UHP FLO-SENSORS will precisely measure flow rates of virtually any fluid as low as 15 mL/minute or as high as 50 L/minute. Repeatable results are achieved by using a patented microturbine flow sensor design. This design, unlike traditional paddlewheel designs, provides accurate flow measurement with no particle generation. PTFE, perfluoroelastomers, and sapphire wetted parts ensure compatibility with chemicals commonly found in microelectronics manufacturing processes, including deionized water, CMP slurries, acids, solvents, and photoresist.

McMillan Model 101 FLO-SENSORS are capable of measuring extremely low liquid flow rates from 13 mL/minute up to 10 L/minute with a full scale accuracy of ±1.0% or better. A wide variety of fluids may be measured. Repeatable results are achieved using a patented Pelton-type microturbine wheel. This proven design has been providing precision results since 1988 and has developed a well-deserved reputation for continuous operational service for many years without failure. Because of the compact size and economical cost of these products, the Model 101 FLO-SENSORS are suitable for a wide variety of industrial, commercial, laboratory and O.E.M. applications. Some sample applications include measurement of hydrocarbon fluids, fuels, light oils, solvents, coolant, pesticides, mild acids, alkalis, and deionized water.

McMillan Model U702 UHP FLO-SENSORS will precisely measure flow rates of virtually any fluid as low as 15 mL/minute or as high as 50 L/minute. Repeatable results are achieved by using a patented microturbine flow sensor design. This design, unlike traditional paddlewheel designs, provides accurate flow measurement with no particle generation. PTFE, perfluoroelastomers, and sapphire wetted parts ensure compatibility with chemicals commonly found in microelectronics manufacturing processes, including deionized water, CMP slurries, acids, solvents, and photoresist.

McMillan Model 106F FLO-SENSORS are capable of measuring extremely low liquid flow rates from 15 mL/minute up to 50.0 L/minute with a full scale accuracy of ±1.0% or better! A wide variety of fluids may be measured. Repeatable results are achieved using a patented Pelton-type microturbine wheel. This proven design has been providing precision results since 1988 and has developed a well-deserved reputation for continuous operational service for many years without failure.

McMillan Model 100 microturbine gas FLO-SENSORS are capable of measuring virtually any clean gas or gas mixture as low as 20-100 mL/minute or as high as 100-500 Lpm! Repeatable results are achieved using a patented microturbine design. This proven design accurately measures flow rates with no zero drift and no maintenance required.
