Metrod (M) Bhd products

Copper content : 99.99 % Minimum. Oxygen content : 10 ppm Maximum. Copper grade : C10100 / OFE, C10200 / OF or equivalent. Condition : Soft. Diameter : 8.0, 10.0 & 14.0 mm. Tolerance : ± 0.38 mm for 8.0 & 10.0 mm;. +0.3 / -0.7 mm for 14.0 mm.

Copper content : 99.99 % Minimum. Oxygen content : 10 ppm Maximum. Copper grade : C10100 / OFE, C10200 / OF or equivalent. Condition : Cast. Diameter : 12.5 – 20.0 mm. Tolerance : +0.20 / - 0.60 mm.

Copper content : 99.99 % Minimum. Oxygen content : 10 ppm Maximum. Diameter : 0.30 – 4.80 mm. Tolerance : ± 1.0 %. Condition : Soft and annealed Electrical conductivity. (IACS @ 20° C) : 100 % Minimum.

Copper content : 99.99 % Minimum. Oxygen content : 10 ppm Maximum. Diameter : 1.20 – 1.50 mm. Tolerance : +0.00 – 0.04 mm. Condition : Semi hard . Electrical conductivity (IACS @ 20° C) : 100 % Minimum.

Copper content : 99.95 % Minimum. Common sizes : 25.0 X 3.0 mm, 50.0 X 6.0 mm. Condition : Soft. Tolerance on dimensions & Corner radius : As per BS EN 13601:2002 or equivalent. Electrical conductivity (IACS @ 20° C) : 100 % Minimum. Elongation at fracture (50 mm gauge length) : 35 % Minimum. Surface condition : Clean, smooth and bright. Brand / Stamping on surface : Metrod. Packaging : In pancake form, duly stretch filmed and palletised on wooden pallet. Coil weight : 45 – 70 Kgs / pancake and 1 MT per pallet. Special requirements /other sizes : On mutual agreement.

Copper content : 99.99 % Minimum. Oxygen content : 10 ppm Maximum. Copper grade : C10100 / OFE, C10200 / OF or equivalent. Size range :Width Thickness Cross sectional area. Width - Thickness aspect ratio :  5 – 52 mm 0.8 – 15 mm 400 mm2 Maximum 2:3 to 15:1. Condition : Soft or Semi Hard. Tolerance on diameter & Corner radius : As per BS EN 13601:2002 or equivalent. Electrical conductivity (IACS @ 20° C) : 100 % Minimum. Tensile strength (Soft) : 210 – 250 N/mm2. Proof stress (0.2%) (Soft) : 70 – 95 N/mm2. Elongation at fracture (50 mm gauge length) : 35 % Minimum. Surface condition : Clean, smooth and bright. Packaging : In wooden spools duly palletised. Sea worthy packing on wooden pallet. Coil weight : Up to 1.5 MT / spool. Special requirements : On mutual agreement. Tensile strength (Semi Hard) : 220 - 320 N/mm2. Proof stress (0.2%) (Semi Hard) : As per customers` request.

Copper content : 99.99 % Minimum. Oxygen content : 10 ppm Maximum. Copper grade : C10100 / OFE, C10200 / OF or equivalent.
