Norris Thermal Technologies products

Standard Equipment (subject to change): Pre-wired electric panel with main disconnect (3-phase, high or low voltage, 50 or 60 cycle). All motors with thermo overload protection, TEFC. Hollow bore gear reducers. Thermometers. Tubular construction, carbon steel. High temperature limit safety switches. Adjustable pitch vane axial fan. Frequency drive on each conveyor drive. Course weave woven wire conveyor belt with roller rack. V-style bottom air chamber. Inlet hopper with adjustable product leveling gate. 2" to 12" of product depth. Conveyor drive roller with rubber lagging, auger idle pulley. Standard temperature designs up to 250 degrees Fahrenhei.

Beltomatic custom-built batch tray drying system promotes consistent air flow across each tray. This unit is built around a wide variety of products with multiple options such as low temperatures that help maintain product integrity. We also offer a variety of heat and fuel sources on this unit as well as the others. Units are available from 200 square feet to 10,000 square feet of drying area.

200 Series conveyor systems are easily installed.They are built, assembled, tested, then shipped for reduced installation costs and quick start-up. Recycle Heat Features (available on all series) - For applications with low moisture content or when heating products. Due to lower plenum design, only the best quality air is recycled. Variable exhaust fan allows operator to control volume of exhaust and recycle air. Recycle heat features are available in single or multiple-state configurations.

Custom Built conveyor systems are easily installed.They are built, assembled, tested, then shipped for reduced installation costs and quick start-up.

PC Series conveyor systems are easily installed.They are built, assembled, tested, then shipped for reduced installation costs and quick start-up. Additional Features: Air up and air down, single or multiple pass, negative air systems. Optional insulation reduces condensation on cooler inner sidewall. Available with exhaust cyclone or exhaust fan. Provides negative air system and compact design.

400 Series conveyor systems are easily installed.They are built, assembled, tested, then shipped for reduced installation costs and quick start-up. Additional Features (all series): Recycles heat from cool section in dryer/cooler models. Adjustable product depth. Carries product to eliminate mechanical damage. Variable airflow for proper airflow selection and conveyor carried on rollers for higher load capacity.

300 Series conveyor systems are easily installed.They are built, assembled, tested, then shipped for reduced installation costs and quick start-up. Additional Features - The multiple pass design gives you additional air-to-product contact plus it increases drying area without depleting floor space. Mixes the product at each drop and increases depth on each additional pass to accomodate shrinkage, improve efficiency and increase resident time.

100 Series conveyor systems are easily installed.They are built, assembled, tested, then shipped for reduced installation costs and quick start-up. Additional Features - Recycles heat from cool section in dryer/cooler models. Have an adjustable product depth and variable airflow for proper airflow selection. Carries product to eliminate mechanical damage, plus the conveyor is carried on rollers for higher load capacity.

500 Series conveyor systems are easily installed.They are built, assembled, tested, then shipped for reduced installation costs and quick start-up. Additional Features - Shown with 8` wide conveyor for high capacity applications and optional cyclones.

Multiple pass design increases air to product contact for improved efficiency. Product enters and exits at the same end of the system. Product is mixed as it drops into the proceeding pass for increased moisture uniformity. Standard airflow is upward. Models can be all heat, all cool, or a combination of heat and cool. Each convener is driven independently; product depth can be adjusted to compensate for product shrinkage, improve efficiency, and increases dwell time. Two pass design increases drying area without depleting floor space. Standard controls adjust airflow, product depth, dwell time, and air temperature. Product depth from 2” to 12”. Width 2’ to 8’ and Length 12’ to 50’ or more.
