PMC Engineering Turkey products

Types: Fine , Coarse, Perforated. Hyrolic or Electric Drive. Fine : 6 ~ 10mm spacing. Channel width: 400 ~ 3,000 mm 75-degree incline angle. Coarse : > 12mm ~ 50mm spacing. Channel width: 400 ~ 3,000 mm, 75-degree incline angle 3mm ~ 6mm perforation. Channel width: 400 ~ 2,000 mm, 75-degree incline angle,.

Size: 200 x 200 mm up to 4000 x 4000 mm. Pressure: up to 1.0 bar for rectangular openings, Mounting with chemical anchor bolts.

Dimensions: 1000 x 150 to 3500 x 1000 mm, 4 sided sealing. Designed for mounting with chemical anchor bolts on concrete wall or embedding with concrete mold.

Available for up to 13m wide and 50m long tanks. Grit removal device. Scum removal device. Control panel.

High separation performance. Dry solid material discharge. Smooth decomposition of the small or large particles. Without bearings, and without water leakage design. Low installation and maintenance costs. Shaft-less heavy-duty screw ensuring durability. No submerged bearings or seals required. Long life and lower maintenance costs. Used in: Water treatment plants, Municipal wastewater treatment plants, Industrial wastewater treatment plants, Chemical industry, Food industry, Paper industry, Refineries, etc.

Impeller Diameter from 0.70 M to 3.6. Vertical shaft surface aerators are easily assembled on all types of fixed bridges. If water level is subject to any changes. Suction nozzle below the impeller increases the effective depth. If the ideal water depth is exceeded, the effectivedepth of Vertical shaft surface aerator can be increased by extending the suction nozzle or providing a draft tube. Vertical shaft surface aerators are manufactured in 18 different power ratings from 1.5 kW to 132 Kw.

Angle adjustable suspension System. Water level independent floating system.

Types: Tubular , Panel or Disc. Produces high efficiency in oxygen transfer and low pressure drop. Can be fitted to any shape of tank. Flexible capacity since quantity can be increased . Specially imported blower.
