Rausch Electronics USA, LLC. products

The Rausch USA pipe inspection CCTV camera system consists of the steerable four-wheel drive L 135 Tractor with an electrical lift and the pan & tilt KS 135 HD camera. The rugged system is built to inspect sewer, water and storm drain pipes from 4″ up to 120″ pipe diameter.

The KS 135 HD Scan has revolutionized the pipe profiling process using the “spinning laser” profiling technology. It is a 3 in 1 system, a single module upgrade to the L 135 tractor / crawler platform. Two laser diodes are integrated on either side of the conventional CCTV camera lens to perform three functions: Conventional CCTV video pipe inspection, Laser profiling (precise measurement of diameter, deflection and deformation of pipe), and crack & joint measurement.

The Rausch USA Lateral Launch System, the M 135, launches a small pan & tilt camera, the KS 60 HD, into laterals from the mainline. It is a module for the L 135 tractor / crawler. Can be sold either as a standalone lateral launch system or as a module upgrade to a mainline TV Inspection, QuickLock Point Repair or Laser Profiling System. Application range from 6″ to 48″ mainline pipe diameter. We now offer the SAT 42 self-leveling lateral camera for laterals as small as 2″.

Currently the most powerful UV light curing system (compact, mobile). Customized versions available (e.g. permanent installation, external control station).

The RRC1 milling robot, with electric drive motors and powerful hydraulics for the robot arm operating in 4 degrees of freedom, has a work platform for holding various tools with modular connection options. A full HD swivel head camera with cleaning lip, which delivers excellent image quality, is used to monitor the work and the exact positioning of the RRC 1. With a characteristic dimension of 162 mm, the robot can be used in pipes with inliners from 200 mm to 1000 mm in diameter and reliably carry out work.

Cubix 300 offers a lot of comfort. It is stable, secured by means of an electric and manual brake function and easy to transport thanks to the integrated carrying handles. Optimum cable guide is ensured by the unwinding aid, cross-lead spindle and foldable arm. The control panel shines with a status display and membrane keys for rear operation. It is optionally available with radio remote control.

Omicron combines two worlds in one CCTV inspection system and is the world`s first Full HD system for pipe and sewer inspections from 50 mm in push and crawler operation. Omicron is the mobile system with compact transport dimensions. The interchangeable basket with quick-release fastener and simple quick-change wheel system support effective work in a targeted manner

The mC30 is for the simple inspection of pipes from 40 mm in diameter. Perfect for inspecting all pipes around the house.

With the mC50 Mono, inspections of pipes are carried out comfortably.
