Serin Trailer Company products

LENGHT: 7.300 mm. 5TH WHEEL HEIGHT: 1.200-1.250 mm. EMPTY WEIGHT ( ±%3): 7200 kg. AXLES: 3 x 9000 kg carrying capacity axle group, drum or Disc type, SERİN or BPW, SAF brand. CHASSIS: SERİN Chassis in compliance with 98/91 EEC standards, formed by automatic submerged arc welding method as I-section made of high-strength steel material specially produced for SERİN. BRAKES: Automatic Load Adjustment Valve RSS (Corning Safety System) Braking System in accordance with 71/320 EEC and 2002/78 EC Standards. LIFTING AXLE: Front axle lifting system that prevents tire wear and provides convenience in turns.

LENGHT: 7.300 mm. 5TH WHEEL HEIGHT: 1.200-1.250 mm. EMPTY WEIGHT ( ±%3): 7400 kg. AXLES: 3x 9000 kg carrying capacity axle group, drum or Disc type, SERİN or BPW, SAF brand. CHASSIS: SERİN Chassis in compliance with 98/91 EEC standards, formed by automatic submerged arc welding method as I-section made of high-strength steel material specially produced for SERİN. BRAKES: Automatic Load Adjustment Valve RSS (Corning Safety System) Braking System in accordance with 71/320 EEC and 2002/78 EC Standards. LIFTING AXLE: Front axle lifting system that prevents tire wear and provides convenience in turns.

Add value to your business with the Serin Trailer Optima Standard Series, which offers large loading capacity for your business.

Overall Lenght : 9.730 mm. Overall Width : 2.550 mm. Fifth Wheel Height : 1.300 mm. Volume : 24 m³. AXLES : Drum or disc type axle with 3*12000 kg carrying capacity (SERIN, BPW or SAF Brand). Chassis : High strength I profile steel SERIN brand chassis fabricated with automatic welding techniques and that complies with 98/91 EEC Standards.

Overall Lenght: 9.400 mm. Overall Width: 2.550 mm. Fifth Wheel Height: 1.300 mm. Volume: 28 m³. Axles: Drum or disc type axle with 3*12000 kg carrying capacity (SERIN, BPW or SAF Brand). Chassis: High strength I profile steel SERIN brand chassis fabricated with automatic welding techniques and that complies with 98/91 EEC Standards.

Semi Trailer Suitable: 6x4 truck. Dimensions: Point of loading length: 8997 mm, Point of loading width: 2190 mm. Payload: 35 Ton. Volume: 35 m3. Fifth Wheel Height: 1350 -1400 mm. Chassis: The Trailer has to lay on a special steel profile which connects the saddles. On the special profile proper reinforcements have to be located for connection points of the running gears. Material is ST52 steel plate according to the dimensions of International Standards.

Fifth Wheel Height: 1300 mm. Suitable for 6x4 trucks. King Pin: 2”king – pin detachable from below made by, SAE standards 8 bolt type. Axles: 3 x 12000 kg carrying capacity SERİN brand. Distance Between Axles: 1320 mm. Brake and Suspension System: Air Suspension, ABS or EBS Brake System. Landing Gears: Double Speed, 24000 kg carrying capacity, JOST brand mechanical Landing Gears.. Rear Bumper: Suitable to 70/221/AT standard of the rear bumper. Suitable to 70/221/AT standard of the rear bumper: Carriers with 1 unit wheel chock. Tires & Wheels: 6+1 PCS 385/65 R 22,5.

Fifth Wheel: 1300 mm. King Pin: Jost Type - SAE standards 2” diameter how is assembled with 8 PCS bolts and is produced from forged 42 Cr Mo4. Capacity: Total Net Capacity: 40 000 lt. Axles: 3 x 12 000 kg Drum Brake SERİN Brand Group. Distance Between Axes: 1320 mm.

Fifth Wheel Height: 1350 mm. Total Length: 12800 mm. Total Width: 2600 mm. Semi-Trailer Suitable for: 6x4 Truck Tractor. Chassis: The Trailer has to lay on a special steel profile which connects the saddles. On the special profile proper reinforcements have to be located for connection points of the running gears. Material is ST52 steel plate according to the dimensions of International Standards.

Length & Truck Tractor Type: 11300mm suitable for 6 x 4 Truck Tractor. Width : 2550 mm. Height of the Syllabus: 4000 mm. Chassis: The chassis of the syllabus semi-trailer is integrated with connection pads welded of the body of the tank shell.
