Shand & Jurs (L&J Technologies & L&J Engineering) products

The Shand & Jurs 95004 Gauge Hatch is designed to provide easy access to storage tanks for gauging product level or temperature and product sampling. Available in a 3 inch model only, it is spark-proof and designed for screw mounting to a threaded tank nozzle. The 95004 features a foot opening cover, which provides for padlocking cover to gauge body. Special cover design, prevents tampering when cover is in locked position.

The Shand & Jurs 95010 Gauge Hatch is designed to provide easy access to storage tanks for gauging product level or temperature or product sampling. Available in 6” and 8” sizes. This gauge provides for emergency venting up to 1 oz./in.2  Featuring a metalto-metal seat, foot pedal for easy opening, and a tape gauge marker. All sizes are drilled to match ANSI 150 Ib. flange.

The Shand & Jurs 95011 Gauge Hatch is designed to provide easy access to storage tanks for gauging products level or temperature and product sampling. Available in 6 & 8 inch sizes, this gauge has provision for emergency venting up to 1 oz./in.2 Design features include a foot pedal for easy opening, metal-to-metal seat, self-closing cover, tape gauge marker and eye for suspending thermometer or a sampler. For mounting, unit can be screwed to tank nozzle.

The Shand & Jurs 95014 Gauge Hatch is designed for easy access to storage tanks for gauging product level or temperatures and product sampling. Available in 4”, 6” and 8” sizes, it is spark-resistant, self-closing and designed for screw mounting to a threaded tank nozzle. This gauge provides for emergency venting up to 3-1/2 oz./in.2 of pressure. Design features include a flexible seal, stainless steel facing on seat, tape gauge marker and a S-hook for suspending a thermometer or a sampler.

The Shand & Jurs 95021 Gauge Hatch is designed to provide easy access to storage tanks for gauging product level or temperature and product sampling.

The Shand & Jurs Model 95210 Clamping Manhole Cover is designed as an economical solution that provides ready access to product storage tanks by means of an easily opened hinged cover.

The Shand & Jurs Model 95220 Clamping Manhole Cover is designed as an economical solution that provides ready access to product storage tanks by means of an easily opened-dome hinged cover.
