180 Degree Elbow
The main function of a Carbon Steel 180 degree elbow is to change the direction of the flow of media at an angle of 180°. Generally, the material used to make these elbows need to have good formability and ductile properties that make forging operations easier. Aside from having the aforementioned properties, a 180 Degree Elbow is a good conductor of heat and electricity and it has superior corrosion resistance to water. Hence, marine engineering is one of the industries that use copper elbows to a broader limit.
Whereas different stainless steel grades offer different properties. For instance grade 304 is a cost effective and popular alloy grade, Stainless Steel 180 degree pipe elbow produced from grades 310, 347 and 321 tend to be heat resistant steels.
The ASME B16.9 is a standard that covers overall dimensions, along with tolerances, testing, ratings, and markings for wrought grade factory manufactured, buttwelding fittings such as the ASME B16.9 180 degree elbow. These fittings are available in a size range between NPS 1/2 through NPS 48 or DN 15 through 1200. Click the link given here for the 180 degree elbow dimensions chart.
