Canon - Model LI8020 -250 MP CMOS Sensor Evaluation Kit
The LI8020 Evaluation Kit Features: Equipped with APS-H 250M pix CMOS sensor. Ultra-high resolution imaging with 250 million pixels (Frame rate up to 5.0 fps). CoaXPressReady. High-speed data transfer (4 x 6.25 Gbps); 3.0 m maximum cable length (operation result) * It depends on the material of the cable. Shooting size changing function. Vertical decimation function for decimating and outputting vertical pixels. Improved shooting frame rate. Partial extraction function for extracting and outputting one subject area from all pixel areas. Reduces image data that is not subject to image capture and improves frame rate (* Vertical only).
NOTE: A Lens is not included in this kit.
As the lens plays a critical role in any imaging system, it is imperative that a suitable lens is selected to properly evaluate sensor performance for your end application.
When selecting an appropriate lens, there are several key factors which must be considered: Lens Type, Lens Mount, Focal Length, Sensor Size, Resolving Power, and Aperture to name a few of the more important ones. Some of these factors are associated with your application, and some are directly tied to how the CMOS sensor will perform. Please read below to learn more.
