Mega - 30 m3 / h Capacity Pan Mixer
We use 3 different mixers in our facilities. PAN Type Mixer, PLANETARY Type Mixer, TWIN SHAFT Mixer. Mixers are the most critical and most important point of the concrete production work in terms of ensuring the mixing process in the shortest time and maximum homogeneity. In our mixers, mixing is provided in a minimum time, at low water-cement ratios and in such a way that all of the cement can come into contact with the aggregate. This is one of the important factors that increase the efficiency of the system. Our Twin Shaft Mixers perform automatic washing and lubrication. In addition, our Pan and Planet mixers have 3 different outputs. Thus, you can use the mortars you have prepared for both your truck mixer and your parquet-briquette machine. Our mixers are guaranteed for 3 years, and our Twin Shaft Mixers also have a 1-year wear plate warranty.
- MIXER TYPE: PAN MIXER (MADE IN TÜRKIYE) – 6 MIXER ARM
- INTERNAL VOLUME CAPACITY: 750 L
- WET CONCRETE CAPACITY: 500 L – TOTAL WEIGHT OF 1200 KG READY MIX CONCRETE
- DRY CONCRETE CAPACITY: 350 L – TOTAL WEIGHT OF 900 KG, PAVER, BLOCK CONCRETE
- DISCHARGE GATE: 3 OUTPUT – DOUBLE ACTION AND LOCKED VALVE / 24 V DC
- COVER DRIVE: ø50 X 300 HYDRAULIC PISTON x 3 PCS
- COVER CONTROL: LOCKED VALVE / 24V DC – STAGE DISCHARGE / OXIM
- ELECTRIC MOTOR: 22 KW – WAT – GAMAK BRAND
- REDUCER: DG 320 – DISSAN BRAND
- BEARING: ø80 HUB BEARING
- MAINTENANCE COVER: 1 PIECE – WITH SAFETY SENSOR
- BASE WEAR PLATE: 15 mm HARDOX – REPLACEABLE – BOLTED
- SIDE WEAR PLATE: 10 mm HARDOX – REPLACEABLE – BOLTED
- MIXER PALLETS: 25 mm NI HARD CASTING – REPLACEABLE -BOLTED
