5-Layers Sintered Stainless Steel Mesh
5-Layers sintered stainless steel mesh is our standard sintered mesh structure. A single layer of fine woven wire mesh is placed between two layers of coarser square woven meshes, which is then added to two layers of a strong Dutch woven wire mesh and sintered together to form a strong plate. The single layer of fine woven wire mesh acts as the filtration layer, and can be customized to meet a particular filtration rating, ranging from 5 micron to 300 microns. It can then be cut and fabricated into various discs, tubes, filter cartridges, and flat panels.
Most popular related searches
Material for sintered mesh
- AISI304;AISI304L; AISI316;AISI316L >> check chemical component
- Special Alloy Steel Hastelloy ,Monel ,Inconel & Titanium are acceptable base on customer`s requirement
Dimension
- Standard size: 500x1000mm ?600x1200mm and 1000x1000mm?1200x1200mm, and other dimensions in between are also available.
Technical Expression
- Initial bubble-point pressure : A bubble the minimum pressure required to force the gas through the liquid impregnated porous material, Pa.
- Average pore size : The average pore diameter determined by the bubble principle, in units of μm.
- Relative permeability coefficient : Unit differential pressure, fluid volume flow through the filter elements per unit area in units of L/min.cm2.Pa
- Viscous permeability coefficient : The unit of dynamic viscosity of the fluid when the fluid resistance is only formed by the viscous losses, the unit pressure gradient, volume flow through the filter elements per unit area in units of m2.
Mesh construction
- 5-layers sintered stainless steel mesh
- 100+filter layer+100+12/64+64/12 @ 1.7mm thickness
- 6-layer sintered stainless steel mesh
- 100+filter layer+100+12/64+64/12+12 @ 3.5mm thickness
