ABC - Model LXB 3000x1000mm - 60mm ...

ABC - Model LXB 3000x1000mm -60mm Sound Vapor Panel

SHARE

Self-supporting sandwich panels, noise insulation and absorption built up from:

Most popular related searches

sound insulation

polyurethane coating

noise insulation

sound absorption

noise absorption

0.6 mm steel plate (outside) provided with profiling, galvanized Z275 and standard equipped with 50 mm polyurethane coating, in colors in accordance with RAL 9002 and RAL 7016 (100 mm)
continuous glued at right angles to the fiber direction cut non-combustible mineral wool for carrying 60 mm and a non-combustible glass wool for the implementation of 100 mm
0.6 mm perforated steel plate stuco, perforation rate 32.7%, galvanized Z275 and provided made of 25 mm polyester coating in standard similar to color RAL 9002

high sound insulation and sound absorption
excellent thermal and fire-resistant properties
suitable for outdoor use
easy assembly

enclosures, screens, booths and interior walls
