Magritek Spinsolve - Model 90 -Advanced Multi-Nuclear NMR Spectrometers
FromMagritek Ltd.
The unique performance of a Spinsolve now at 90 MHz. Sensitivity measured in a single scan on a 1% ethylbenzene sample dissolved in deuterated chloroform. The signal used for the calculation is the one of the methylene group and the noise is calculated for a signal free region between the aromatic and the methylene signals.
Most popular related searches
- H frequency: 90 MHz
- Highest Sensitivity: >240:1 (Dual channel for 1% Ethyl Benzene1)
- 1H and 19F on all systems + X nuclei for dual channel systems
- Resolution Spinsolve 90 MHz: <0.4 Hz (50%) / <16 Hz (0.55%)
- 3D PFG gradients optimized for gradient-enhanced methods
- Optional PFG gradients for diffusion spectroscopy (>0.25 T/m)
- No cryogens
- External Hardware Lock with no need for deuterated solvents
- Unparalleled stability
- Suitable for on-line reaction monitoring
- Easy to operate
- Available with automatic sample changer
- Benchtop size and weight
- Dimensions: 66 x 45 x 43 cm (25,9” x 17,7” x 16,9”)
- Weight: 115 kg (253,5 lb)
