Alpha-Pure - Model EF Series -GT Compressed Air Filters

GT Series Filters employ TIE ROD MOUNTED (EF) ELEMENTS. This style allows for easy rod-mounted element changes but requires enough vertical clearance to remove the filter body from the element length. (see the GX SERIES if vertical clearance is a consideration) Deep pleating technology delivers superior filtration and very high dirt holding capacity. Engineered to remove airborne contamination from compressed air, the filters deliver energy efficient operation and reliable performance. Maximum Operating Pressure: 290 psig (20.0 bar). Maximum Operating Inlet Temperature: 176F (80C). Differential Pressure for Element Change: 10 PSI
