Baykon Inc.
Baykon - Model TX2 -Digital Weighing Transmitters
FromBaykon Inc.
TX2 digital transmitter family is designed for static or dynamic weighing and force measurement processes to provide fast and accurate digital data through RS-232C, RS-485, Ethernet TCP/IP and bus systems as Profibus, Modbus TCP, Modbus RTU, Profinet, CANopen, EtherNet/IP, EtherCAT, CC-Link, Powerlink.
Weighing functions such as Zeroing, Taring, Power-On zero, Net indication at power on, Motion detection, etc. are integrated in TX2 transmitters. Configurable vibration suppression digital filter settings and calibration with test weight or electronic calibration without test weights ( eCal ) via Windows based BAYKON xFace software. DIN rail type enclosure provides easy montage in control panel.
Most popular related searches
Features
- Communication: Reliable data transfer with industrial communication protocols for various for PLC / DCS or PC systems
- High speed: 800 conversion/sec.
- Weighing functions: Zeroing & taring, power-on zero, AZT, net indication at power on, motion detection
Software support: Windows based BAYKON xFace software for calibration and setup via PC
- eCal: Electronic calibration without test weight
- Vibration filter: Configurable active filter for stable weight
TX2MB - HT
- High temperature operation
- Double channel
- Max. 100°C
- Modbus RTU communications
