The Batch Mixer is engineered to optimize the growing substrate in containerized nurseries by ensuring a homogeneous mix of both organic and inorganic components. Organic materials such as peat moss, composted bark, rice husk, and coconut husk are combined with inorganic elements like perlite, vermiculite, sand, and pumice to create a balanced substrate. This precise mixing enhances seed germination rates, the success of cuttings rooting, and the uniform development of nursery plants, thereby minimizing losses. The Batch Mixer boasts specifications including item code BAMI, dimensions of 2400 x 1200 x 2200 mm, a hopper capacity of 1.5m³, a power supply of 3 x 400V, and a power requirement of 3kW. Additionally, it consumes 20 liters of compressed air per minute at 6Bar and 20 liters of water per minute at 2Bar. It also includes a media feeding belt with dimensions of 4500 x 500 x 2300mm and requires either a 1 x 230V or 3 x 400V, 50Hz power supply and 0.37kW power.
Most popular related searches

Growing substrate in containerised nurseries supplies water, oxygen, mineral nutrients and physical support to the plants.

To achieve the characteristics of an ideal substrate for containerised plant production, organic and inorganic
components are generally mixed together. Organic components include peat moss and composted organic materials e.g. bark, saw dust, rice husk, coconut husk and sugar cane bagasse. Inorganic components include Perlite, vermiculite and other inorganic materials e.g. sand, pumice, rock wool and polystyrene flakes. Additives such as slow-release fertilisers or dolomitic lime (for pH correction) can also be added to the mix.

Even and homogeneous mixing of these components ensures an increase in seed germination rate, rooting
success with cuttings and even development of plants in the nursery, minimising losses.

Item Code: BAMI

Dimensions (L x W x H) mm:
2400 x 1200 x 2200
Hopper capacity: 1,5m3
Power supply: 3 x 400V
Power requirement: 3kW
Compressed air consumption:
20 litres/minute at 6Bar
Water consumption: 20 litres/minute at 2Bar

Media Feeding Belt Dimensions
(L x W x H): 4500mm x 500mm x 2300mm (belt width 300mm)
Power supply: 1 x 230V or 3 x 400V, 50Hz
Power requirement: 0,37kW
