Zaxis - Model VMP1-M/V/VS -Benchtop eVmP Enclosure

The VMP1-M/V/VS is a benchtop version of the Zaxis VMP line which includes an integrated 7” capacitive touchscreen as well as 24V digital I/O controls and EtherNet/IP™. The Touchscreen rotates 9 degrees for easy viewing or can be mounted externally. The VMP1-V/VS has a splashproof stainless steel enclosure that allows you to switch the pump head on the right or the left. This enclosure is compatible with either the M or V series stepper or servo drives and M or V series pump heads. No need to supply 24V as the power supply is mounted internally. You can plug this unit directly into a 120V outlet. If you need to switch to a different pump head, then you only need to remove two screws. The VMP1-M/V/VS can be used in automation via RS485, EtherNet/IP™ or 24 VDC digital I/O.
