Berg - Clamp-on Flow Meters
The acoustic attachable flowmeter is suitable for fixed installation for continuous measurements. Two ultrasonic transducers are mounted on the pipe and connected to the electronic unit by a signal cable Thanks to this strap-on technology, these ultrasonic transducers can be installed in just a few minutes. Time-consuming cutting of the pipe is not necessary. This means that pressure losses and process downtimes can be avoided, and operating costs optimized.
The meter uses the proven and precise ultrasonic transit time difference method. By using the latest digital signal processors, the flow sensor operates extremely accurately and virtually drift-free.
Since the sensors do not come into contact with the medium, the measurement is 100% contamination-free and thus absolutely hygienic. This is particularly interesting for volume measurements of food and pharmaceutical products. When measuring toxic or environmentally harmful liquids, there are no additional sealing surfaces or dead volumes.
- Fixed ultrasonic flowmeter
- Measurement of ultrasonically conductive liquids including temperature recording
- Liquid and viscous media
- Flow and heat quantity measurement
Continuous flow: –30…+30 m/s²: -30 … +30 m/s²
Medium temperature: –40…150°C - High measuring accuracy
- Communication interface (option) Modbus RTU or M-Bus
- Retrofittable without interruption of operation
- Hygienic measurement
- Fast installation and commissioning
- Measurement method : Ultrasonic transit time difference
- Signal processing : DSP based, cross correlation
- Measured quantities : Volume flow, flow velocity, heat output, sound velocity of the fluid, heat quantity with optional PT100
- Meter : heat quantity, volume
- Measuring range : –30…+30 m/s
- Calibration function : PT100, flow rate
- Signal damping : 0…100 s (adjustable)
- Diagnostic functions : Sound velocity, signal strength, SNR, signal quality, amplitude, energy
- Signals can be shown graphically on the display
- Operation : Intuitive via 6 main keys (soft keys)
- Languages : D, UK, FR, RU, ES, CHN
- Units : Metric/UK/US
- Outputs : 2× 4…20 mA (active or passive, potential reference)
- 1× pulse (potential reference)
- 1× relay (potential-free)
- 1× optional RS232 or RS485
- BUS communication : ModBus (RTU, ASCII) via optional RS485 interface
- (Format: Request, Function 04)
- Inputs : 2× US converter, 2× PT100 (for heat quantity measurement)
- Power supply : 90-264VAC, optional 18-36VDC
- Protection class : IP65
- Cable connections : Screw terminals
- Dimensions (W × H × D) in mm : 260 x 240 x 120mm
- Calibration : ISO 9000-based factory calibration certificate on request
