Bright - Membrane Plate
The application of membrane filtration technology has filtering effects significantly. The final dewatered cake is a result of mechanical squeezing by the membrane. Bright high pressure PP membrane plate can achieve squeezing pressure up to 2.0MPa. The high pressure PP membrane plate is the latest and the most practical new type filter plate.
Most popular related searches
membrane filtration system
filter plate
dewatering cake
membrane filtration
filter press
dry cake
cake dewatering
filtration membrane
dewatering
It has three major advantages than conventional recessed chamber filtration:
- Reduced filtration cycle times
- Increased cake dry solids
- Improved cake wash capability
- Supplier: Bright filter press
- Place of Origin: Shandong, China (Mainland)
- Size: 630, 800, 1000, 1200, 1250, 1500, 1600, 2000, 1500×2000mm
- Type: Membrane plate
- Material: Virgin PP
- Feeding type: Center feed, corner feed, top center feed
- Cake thickness: 25-40mm
- Plate thickness: 60-95mm
- Max feed pressure: 3.0MPa
- Max squeezing pressure: 5.0MPa
- Max temperature: 80 oC
