Brumby Pumps - Model XS1 -Small Child Installs Submersible Pump
FromBrumby Pumps
XS1 pump - 750mm (2`6") x 90mm (3.5") designed for cleaning out of silted wells/bores, but also used where: Water depth is and remains over 1/3 of the total vertical lift. The deeper you can submerse the pump in water, the more it will deliver. Water level self-regulates by virtue of the pump`s design and operating principle. Pump will still operate with substantially reduced submersion/lift ratio, but water delivery rate may be low.
Most popular related searches
submersible pump
water level regulator
water source
source water
water regulations
water supply
submersible water pump
pipe lifting
water piping
water pipe
- Water level self-regulates by virtue of the pump`s design and operating principle.
- Delivery rate can be as much as 7000L/hr, depending on the water source, submersion in water, lift above the water, air supply and piping size.
- Vertical lift up to 100m (300ft) is no problem with a regular 5 to 15cfm off-the-shelf compressor, although this model is best in shallower bores. If the lift is higher, please contact us to discuss.
- Submersion in water should be no more than around 60m (170ft) if using a regular 130psi compressor.
