BS&B - Model RE/RE-7R -Replaceable Element Disks

SHARE

The unique fail safe design of the RE™ type disk assures the disk cannot be installed incorrectly in the safety head as the disk will burst at its rated burst pressure in either direction. Additionally, the disk and safety head assembly may be installed in either direction between pipe flanges. A disk with a burst pressure of 22psig (1.52 bar) or above will withstand full vacuum.

Most popular related searches
pipe flange
flanged pipe
safety regulations
machine safety
  • RE-7R™ Safety Head
    The RE™ type disk is installed in a precision machined RE-7R™ safety head for direct installation between standard international pipe flanges
  • Flange Ratings
    The safety heads are designed to fit between all standard international pipe flanges, ANSI, DIN, AFNOR, BS, JIS and to nestle within the flange bolts
  • Material
    Safety heads are available in impregnated graphite or 316SS as standard
  • Patented: US 5,121,847 Japan 2611105
