BHDT - Butterfly Valve

Control valves control the pressure and flow of a chemical plant in dependence of the operating parameters.

Most popular related searches

Nominal size: DN3-DN89 or bigger
Nominal Pressure range PN700-PN4000
Materials: various materials for chemical plants according to customer requirements
Body type: acc. customer specification
Inlet/Outlet type: acc. customer specification
Internal sealing system: Lens ring sealing, MSI-ring, Silverring
Actuator types: Hydraulic-, Pneumatic-, Electricactuator
Design codes: ASME, AD2000, PED, CE marking
Controller: Hydraulic-Servovalve; Pneumatic-Positioner
Feedback: Hydraulic-LVDT
Control signals: different signals possible

Main Features
