Cannon - Model miniPV -Fully Automated Single-Sample Benchtop Viscometer

Viscosity range for dilute solution viscosity is 0.3 mm²/s (cSt) to 700 mm²/s (cSt)* and for kinematic viscosity 0.02 mm²/s (cSt) to 1,200 mm²/s (cSt)* at 15 °C to 100 °C.

Protect your investment and ensure your instrument continues to provide quality and reliable results for years to come with a CANNON Service Plan.

Designed to meet your viscosity testing needs

• On-board software with specialized polymer calculations determines inherent, intrinsic, kinematic, reduced, relative, and specific viscosity, as well as, molecular weight
• Integrated TE cooling provides superb temperature control from 15 °C to 100 °C
• Dilute solution polymer viscosity range: 0.3 mm²/s (cSt) to 700 mm²/s (cSt); both single range and special dual range viscometer tubes are available*
• Kinematic viscosity range: 0.02 mm²/s (cSt) to 1,200 mm²/s (cSt)*

Compact,robust design

• Fits in roughly the same benchtop area as an analytical balance to conserve valuable lab space
• Sealed system allows for measurement of atmospherically sensitive and volatile samples
• Compatible with most aggressive aqueous, aqueous, caustic, halogenated, organic, and salt solutions

Fully automated benchtop testing

• Software controls the instrument and facilitates tasks such as calibration, data entry, method specification, calculation selection, report formatting, and data exporting
• Single PC manages up to 4 instruments using VISCPRO® software
• Reduces operator to operator variability
• Replaces manual tube cleaning with automated washing and drying

Simplified maintenance & test versatility

• Modular bath for easy maintenance access
• Operators physically replace tubes in minutes, eliminating the need to schedule related service calls
• Single-point temperature calibration avoids need for tube recalibration and maximizes test flexibility
• Standard dual solvent input
