Herberts - Model SGL - LED -Circular Light Fitting

Applications

• Clamp fitting to
  DIN 326767 / ISO 2582 /BS4825

Advantages

• Space-saving application for viewing and illumination
• Sanitary design
• Safety against total failure
• Easy installation
• Long operating time

Technical datas of sight glass

• Pressure equipment directive 2014/68/EU,
  AD 2000, DIN 7079
• Materials according to VdTÜV and
  the intended  DIN/EN standards
• Glass: Borosilicate glass according
  to DIN 7080 / DIN 7079

Material approvals

• Certificate of Conformity to EN 10204-3.1 or 3.2

 Technical datas for luminaire

• Evenly, glare, contrastry illumination of agitators, tanks, vessels, pipes in nonhazardous areas
• Very compact, easy to clean design
• Body: 1.4404, polished
• Light color: white (WS)
• Voltage: 24VDC (+-10%)
• Light flux: 266 - 400lm
• Current, continuously: 100 mA
• Ambient temperature: 0°C to 50°C
• Protection class:  IP68
• UL-compliant

Equipment

• wire for push button with timer (1 min)
