Wantai -Â Model 86HBM -Closed Loop Stepper Motor
86HBM Closed Loop Stepper Motor is equipped with a 1000-line incremental photoelectric encoder, which has high precision, low motor heat generation, low noise and high efficiency. The motor stops at high speed and is stable and fast, without zero-speed oscillation, runs smoothly, and has a fast response speed, suitable for frequent Start and stop occasions.
Most popular related searches
hybrid stepper motor
hardness testing
inspection system
metals testing
non-destructive testing
non-destructive testing system
inspection data
microscopy
inspection microscope
NDT testing
- Frame number: 86
- Holding torque: 4. 5~12. 7N. M
- Length of body: 78~150mm
- Equipped with 1000-line incremental photoelectric encoder, high precision
- The motor has low heat, low noise and high efficiency
- High-speed stop is stable and fast, without zero-speed oscillation, running smoothly, with low vibration and noise
- Phase current: 5. 6A
- Strict contract auditing invloved all departments to assure the feasibility of each order.
- Process design and validation before bulk production.
- Strictly control on all raw and auxiliary materials, All raw materials reach the world advanced level.
- On-site inspection to all processes, inspection record keep traceable for 3 years.
- All inspectors are skilled with international certificates.
- Qualified WPS and professional welders guarantee welding quality.
- 100% inspection of finished sprouts before shipment.
- Advanced and complete testing and inspection equipment: NDT, metal Microscope, impact tester, hardness tester. . .
- Regular training for inspection staff
