bioCycle™ - Commercial Wastewater Treatment Systems
The bioCycle™ Commercial Treatment System is designed for large-scale wastewater treatment applications, incorporating a series of robust stages to ensure effective pollutant removal and compliance with stringent discharge regulations. The system begins with primary chambers, where sludge undergoes prolonged anaerobic digestion, reducing solid content and minimizing desludging frequency. Aeration chambers utilize fixed film reactors with high specific surface area media to foster bacterial floc formation and promote aerobic digestion. Advanced flow control baffles create anoxic zones for denitrification and phosphorus removal. The clarification chamber facilitates the settling of bacterial flocs, with settled sludge cycled back to primary stages. Treated effluent is temporarily stored in pump chambers, and polishing filters further purify it through soil or sand filtration, achieving high nutrient and contaminant reduction. This modular design is optimized for various commercial environments, including visitor centers, golf clubs, hotels, and housing schemes, with systems handling hydraulic flows from 3.9m³ to 63m³.
bioCycle™ specialise in the design, installation and servicing of commercial wastewater
treatment systems ranging in size up to 1000 P.E. Systems can be designed to meet the most stringent of discharge licenses and can incorporate UV disinfection, denitrification and phosphorous removal processes.
The main advantages of the bioCycle™ system are:
- Highest Treatment Performance
- Longest Desludging Intervals 7-10 Years
- Agrément Certified
- Proven system with over 20 years successful operation
- Reinforced Concrete Tank
- Tested & Certified to EN 12566-3
- Multiple Safety Featuresn
1. Primary Chamber
bioCycle™ wastewater treatment systems incorporate large primary chambers to allow extended sludge retention. Sludge when stored for greater than 18 months will degrade through anaerobic digestion. The advantage of extended retention in the primary chamber is that the system will require infrequent desludging; also the solid content will be significantly reduced thus reducing the pollutant load entering the secondary treatment stage. Sludge from the clarification stage is returned to the primary chambers for storage.
2. Aeration Chamber
The bioCycle™ system is a fixed film reactor. Aerobic bacteria breakdown the waste and in the process consume oxygen. As a result, oxygen is supplied at this stage via air blowers. Media with a high specific surface area is contained in the secondary treatment chambers, providing the optimum environment for bacterial flocs to form. Flow control baffle walls allow anoxic zones to be created at the end of the chambers, resulting in denitrification and phosphorus removal process to occur.
3. Clarification Chamber
The clarification chamber is designed to provide quiescent conditions allowing any bacterial flocs remaining in the effluent to settle out. Sludge from the clarification stage is returned back to the primary and secondary treatment chambers.
4. Pump Chamber
The large pump chamber allows the treated effluent to be stored before it is pumped to the polishing filter or surface irrigation system. The pump is operated intermittently to ensure low energy usage.
5. Polishing Filter (Percolation Area)
bioCycle™ provide a range of designs of polishing filters which are installed by our experienced crews. The treated effluent is pumped to the topsoil layer where it is allowed to percolate through the filter media (soil or sand) where further reductions in nutrients and bacterial contaminants will occur.
