Sauermann - Model Si-83 Pack 2 -Condensate Tank Pump
FromSauermann Group
Sauermann engineers have redesigned the tank pump from the inside-out, making the Si-83 more compact than any other tank pump in its class, all while redefining just how easy tank pump installation and maintenance can be in the field. The Si-83 even comes with a customized Smartphone App that makes installation both simple and intuitive. The Si-83 is constructed from rugged materials and components for exceptional durability and reliability. The Si-83 tank pump from Sauermann is perfect for residential A/C (up to 20 kW) and heating units (up to 40 kW).
Most popular related searches
condensate pump
condensate pumping
PVC tubing
centrifugal pumping
check valve
centrifugal pump
single cartridge pump system
boiler condensate
centrifuge
tank maintenance
- Exceptional Durability and Reliability
- Quick & Easy Maintenance
- Quick & Easy Installation in any place
- Regular Duty
-
Max discharge head 5.4 m
-
Max pressure 5.7 m
-
Mains supply 230 V~ 50 Hz - 115 W – 1.4 A
-
Operation conditions 7%: 16s ON - 212s OFF
-
Max condensate temperature 55 °C
-
Max condensate acidity pH > 2.5 (Gas condensing boilers)
-
Tank volume 2 L
-
Weight 2.4 g
-
Master pack quantity 72
-
Safety switch NC: 5 A resistive 250 V (SI83CE02UN23), NO: 5 A resistive 250 V (SI83CE42UN23 & SI83CE43UN23)
- 1 One-piece centrifugal pump with 2 l tank
- 1 Integrated barb end check valve, Ø ext. 10 mm
- 1 1.8 m power cord, plug
- 1 Built-in safety switch, 1 m wires, bare ends, NC (SI83CE02UN23) or NO (SI83CE42UN23, SI83CE43UN23)
- 2 screws, 2 plugs
- 1 Multi adaptor to be used for Ø 15/17 - 20 - 24/25 - 32 - 40 mm tubes
- 1 Clear PVC tubing Ø int. 10 mm, 5 m roll
- 1 pH Safe 1 Neutralization Cartridge (SI83CE43UN23 only)
