Gouda-Geo - Model 200 kN -Cone Penetration Testing (CPT) Container
The 200 kN CPT container is a stand-alone unit that can be used in a variety of conditions, both onshore and offshore. It can either be mounted on a truck, a railway lorry or jack-up barge. It contains a hydraulic 200 kN short-stroke CPT pusher and is to be connected to an external power-pack.
Most popular related searches
stainless steel tube
cone penetration test
manually operated valve
CPT penetrometer rig
hydraulic valve
hydraulically operated valve
cone penetration test penetrometer
penetrometer rig
cone penetration
manual valve
- Dimensions (L x W x H): 295 x 250 x 224 cm
- Weight: 1650 kg
- Pushing capacity: 200 kN
- Pulling capacity: 260 kN
- Testing speed: 2 cm/sec
- Clamping device: mechanical push-and-pull clamp (more info here)
- Catching clamp integrated in the support beam of the pusher (more info here)
- Stainless steel tube rack, capacity: 40 CPT tubes + 24 casing tubes
- Lighting
- Antiskid floor with inspection hatch
- Windows
- Manually operated hydraulic valves
- Entrance door
- Corner castings and twist locks
- 4 lifting eyes
- Clamping device: mechanical push-and-pull clamp (more info here)
- Catching clamp integrated in the support beam of the pusher (more info here)
- Stainless steel tube rack, capacity: 40 CPT tubes + 24 casing tubes
- Lighting
- Antiskid floor with inspection hatch
- Windows
- Manually operated hydraulic valves
- Entrance door
- Corner castings and twist locks
- 4 lifting eyes
