Kerui - Model 750HP/1700kN -Conventional Land Drilling Rig

LThe land drilling rig is usedfor oil and gas exploration and development on wells that are I600~3000m (drill pipe 4 1/2") or I500~2500m (drill pipe 5") deep. Max. drilling depth 3,000 m. The rig with modular design and compact structure. The rig driller control cabin with electric & air & hydraulic oil control, which can reduce labor intensity and improve the working environment. The rig driving model could be VFD, mechanical or combined drive, client could require the rig model. The rig substructure model could be box-on-box or swing-up, with compact structure. The generator house with noise-insulation design, to reduce environment pollution and human harm.
