Crown - Single Screw Extruder
Ideal for production, material testing, new product development and quality control purposes, and used in various processes such as compounding, pelletizing, sheet extrusion, pipe extrusion, wire coating and blown film. Available in 1 1/2", 2 1/2", 3 1/2", 4 1/2", 6", 8", 10" and 12" diameters with variety of standard and custom-designed screws and barrels are available for various applications.
Most popular related searches
single screw extruder
materials testing system
digital temperature controller
worm gear reducer
chart recorder
material testing
rupture disc
screw extruder
pipe coating
pressure reducer
- Hardened alloy steel or bimetallic cast liners for added wear and chemical resistance
- Rupture disc port protects against excessive pressure build up
- Reduced root diameters in the venting area allow for efficient single or multi-stage venting
- Vacuum system with separator on the extruder frame is easily accessed for cleaning and maintenance
- Screws finished with Stainless steel, Dura-nickel, nitride hardening chrome or plasma coating
- Incorporates the latest technology: DC ammeters, digital speed indicators, heat zone meters, pressure gauages, melt thermocouples, strip chart recorders, and any other custom instrumentation as required
- Control and monitoring units are easy to operate, and allows for the process to be monitored at each stage of the production
- Barrels are divided into heating and cooling zones for greater temperature specificity
- Heating is derived from resistance heating elements and cooling from the use of air or fluid
- Temperature of each barrel zone is controlled separately
- Auto tuning PID temperature controls display set point, present value and digital amp meter and heater open alarm
- Low noise gear reducers with integrate torque distribution
- Standard AC inverter drives for excellent torque over speed range
