This product is designed for applications that require reduced product evaporation and elimination of frost and condensation during transfers. The combination of vacuum jacket and super insulation make this product the optimal efficient flexible transfer line. Built to customer specifications, the lines can be fabricated to fit a multitude of applications. Inner diameters range from 1/8" to 6" and lengths up to 100’ in one continuous length (consult factory for specific length capabilities). It can be used with ALL liquid cryogens from LNG to liquid helium depending on the end fittings. A full line up of bayonets, pipe threads, compression and custom end fittings are available. Hose assemblies can also be fabricated full length protective ARMOR casing or cuffs.
- All liquid cryogens
- Applications that require reduced product evaporation and elimination of frost and condensation during transfers
- Vacuum-jacketed and super-insulated
- Stainless steel braided and Welded exterior
- Flexible transfer line
- Inner diameters range from 1/8″ to 6″
- Up to 100′ in one continuous length
- Full line of bayonets, pipe threads, compression and custom end fittings
- Can be fabricated with full length protective armor casing or cuffs
