Linetronic - Model LT/CB -Cryostat and Low Temperature Thermostatic Bath and Circulator

LT/CB-40800-M/10
LT/CB-40800-M/20
LT/CB-40800-M/30Professional Cryostatic Bath, 8 litres capacity, composed by:

• Internal chamber in seamless stainless steel with rounded corners for efficient circulation and cleaning
• Control head with digital display showing the set temperature and actual temperature, resolution 0,1°C and precision ±0,1°C; RS232 connection
• Safety thermostat manually settable for overheating protection
• Circulating pump: 80 cm prevalence for external application (3,5 lt/min)
• Frontal grid easily removable for cleaning the exchanger
• Double main switch

LT/CB-41800-M/10
LT/CB-41800-M/20Professional Cryostatic Bath, 18 litres capacity, composed by:

• Metallic case structure painted with anti-acid products with double wall heat insulation
• Internal chamber in seamless stainless steel with rounded corners for efficient circulation and cleaning
• Control head with digital display showing the set temperature and actual temperature, resolution 0,1°C and precision ±0,1°C; RS232 connection
• Safety thermostat manually settable for overheating protection
• Circulating pump: 80 cm prevalence for external application (3,5 lt/min)
• Frontal grid easily removable for cleaning the exchanger
• Double main switch

Power Supply

• 220 or 115 Vac 50/60 Hz
