Stevens SatComm - Model GOES Satellite Transmitter -Data Collection Transmitter
Stevens’ SatComm is a satellite communication radio certified by NESDUS / NOAA for remote environmental monitoring data transmission via the GOES (Geostationary Operational Environmental Satellite) Data Collection System (DCS). The GOES system covers North, Central, and South America. This system is particularly beneficial for monitoring water levels, weather conditions, and other environmental parameters in remote or inaccessible locations. NESDIS (National Environmental Satellite, and Information Service is under NOAA (National Oceanic and Atmospheric Administration) – an agency of the US Department of Commerence.- NESDIS CS2/v2.0 certified
- Compatible with most 3rd party data loggers
- Two data logger input modes:
- Continuous listen to data logger mode
- Trigger mode using CTS “clear to send”, with programmable advance turn-on time
- Two-way communication port
- Available with integrated data logger (4 analog, 1 pulse and 12 SDI-12 sensor inputs, 1 control output)
- VSWR measurement ensures proper antenna connection after installation, and alerts you of potential problems proactively
Stevens SatComm is fully compatible with most 3rd-party data loggers (connection via standard RS-232 port) or can be configured with an optional integrated data logger, allowing for basic data collection tasks and data transmission to be performed within one compact unit.
Stevens SatComm uses a TCXO (temperature compensated crystal oscillator) to provide exceptional power efficiency, minimal frequency aging and unsurpassed longevity.
Unlike OCXOs (oven-controlled crystal oscillator) typically used, a TCXO:
- reduces the overall power consumption by eliminating a high current oven, eliminating the time and need for warm-up
- is not vulnerable to breaking due to power cycling
- maintains frequency over time without drift
- minimizes the risk of station failure due to constant power-cycling, and ensures that transmissions always occurs within assigned timeslot.
User-selectable station health status information can be prepended to each transmission (battery voltage, message number, lat/long, VSWR, internal temperature, etc.), allowing remote alerting of potential problem conditions.
Data redundancy allows previous data set to accompany the current data set, increasing the chance of data retrieval even if a transmission is lost.
Two secondary COM ports (Touchscreen port and DCP Command port) allow dual telemetry (cellular, Inmarsat, Orbcomm, Iridium, etc.) for redundancy and 2-way remote station configuration and diagnosis.
VSWR measurement ensures good connection and signal path from the SatComm’s RF output to the antenna before the technician leaves the remote station. VSWR is continuously monitored as well, to protect expensive equipment in the event of damage to the RF connections, cabling, or antenna.
Power requirements
- Input voltage range: 10.5 to 16 VDC
- Quiescent: 2.0 mA (in CTS trigger mode)
- During GPS acquisition: 350 mA
- 300 BPS transmission: 2.4 A (3 W max. with V2TH antenna)
- 1200 BPS transmission: 3.5 A (10 W max. with V2TH antenna)
Maximum output power
- 300 BPS transmission: 34.77 dBm (3 W max.)
- 1200 BPS transmission: 40.0 dBm (10 W max.)
External interfaces
- Computer interface: USB type-B
- External logger: DB9-m connector interface
- External touchscreen: DB9-f connector interface
- DCP command: DB9-f connector interface
- LED indicators: Transmit, receive, failsafe, power, GPS lock status, built in self test (BIST)
Timekeeping
- Transmission timing accuracy: Meets NESDIS specifications
- GPS time accuracy: Within 0.01 s (10 ms) UTC
Certified antennas
- Stevens V2TH: +5.5 dBic gain, RHCP
- Stevens V4TH: +10 dBic gain, RHCP
- Stevens Yagi: +11 dBic gain, RHCP
Data transmission
- Reporting: Self-timed or random reporting
- Format: ASCII or pseudo binary
Physical
- Temperature: -40° F to +149° F (-40° C to +65° C)
- Humidity: 0 - 95% relative humidity non-condensing
- Dimensions (W x L x H): 4.625” x 8.81” x 2.096” (11.75 x 22.38 x 5.32 cm)
- Length Including mounting plate: 7.169”, face-to-face
