Viatran - Model 590 -Detachable Level Transmitter

• Detachable
• All Stainless Steel construction
• IP-68 Rated
• Low Pressure Applications
• RoHS Compliant

The Model 590 Detachable Level Transmitter allows for a quick sensor swap without the removal of the installed cable. No special tools are required. Simply pull up the sensor, twist the sensor coupling sleeve till it is no longer engaged and then simply separate the two halves.

590 is contructed of stainless steel housing and sensor module, with a polyurethane cable as standard.  Different cable materials and o rings are available.

Use it to measure Liquid Level and Depth for Water and Waste Water applications, at Lift Stations, Reservoirs and Dams, Rivers, Holding Ponds, Wells, In-ground / Above Ground Tanks and with Inventory Tank Gauging.

Ranges from 0-40"WC thru 15 `WC have combined accuracy of +/- .50% FSO

Ranges greater than 15` WC have combined accuracy of +/- .35% FSO

Viatran also offers a complete range of accessories for use in level applications such as a surge protector, cable hangers and weights, meters and junction boxes.

Replacement sensor heads and/or cables can be purchased separately

Performance
Pressure Ranges 0-40 Inches Water Column up to 0-835 Feet Water Column
Combined Accuracy (Non-Linearity, Hysteresis, Repeatability) ≤ +/- 0.50% FSO for ranges < 15 Ft. W.C.
Compensated Temperature Range 2° to 158° F (0 to 70° C)
Operating Temperature Range 4° to 158° F (-20 to 70° C) Note: Medium must not freeze near sensor
Storage Temperature Range -13° to 158° F (-25 to 70° C)
Long Term Stability (%FSO) ≤±0.1% FSO / year at reference conditions
Thermal Effect on Zero ≤±0.8% FSO per 100° F
Thermal Effect on Span ≤ ±0.8% FSO per 100° F

Electrical
Output Signal 4-20 mA
Supply Voltage 8 -32 Vdc
Power Supply Regulation Circuit Protection Reverse polarity protected, CE marked
RFI/EMI CE EMC compliant as per IEC EN 61326
Voltage Spike Protection Withstand 1000 volt spike per EN 61000
Response Time <10mSec

Mechanical
Pressure Connection Protective POM cap
Ingress Protection IP 68
Overpressure Limit 4x Minimum (>335 Ft. range = 3.2x)
Burst Pressure 5x Minimum (> 335 Ft. range = 4.8x)
Weight 0.9 lbs. (without cable)

Materials of Construction
Housing 316L stainless steel
Sensor Diaphragm 316L stainless steel
O-ring Seals FKM or EPDM (customer specified)
Protective Cap POM (Polyoxymethylene)

Options
EA Special Calibration Run
PW Calibrate item with meter/display
