Purion - Model 400 -Disinfect Drinking Water Equipment
UV-plant PURION 400 can be equipped with a polished stainless steel reactor. PURION 400 can be used to disinfect drinking water up to a flow rate of 300 l/h and for a transmission of at least 90% per cm. The used uv lamps are characterized by a long durability and a high degree of efficiency respecting to disinfection and energy consumption. The power supply can be carried out with 230 V/50 Hz or optionally 12 V DC, 24 V DC or 110 V AC. The compact construction design enables an easy replacement of the uv lamp at the end of their useful life. You don`t need any tool. Also replacement and cleaning of the quartz pipe can be arranged easily.
UV disinfection is reached by floating the water through the reactor. Inside the reactor an uv lamp enclosed in a uv-c transparent quartz pipe is surrounded by the drinking water to be treated. The small distance of 7.5 mm between the quartz pipe and the inner surface of the reactor ensures optimal irradiation and therefore optimal disinfection of the water.
manufacturer: PURION GmbH
type: PURION® 400
flow rate: 300 l/h drinking water
UVC-transmission: 90% T1 cm
temperature of the water: 2ºC to 40ºC
reactor: stainless steel 1.4571
flanges: R 1/2" external thread
seal: FPM
dimensions (L x Ø): 237 x 42
distance flanges: 172 mm
weight: 1,9 kg
life time of lamps: 10.000 h
number of lamps: 1
dose: 400 J/m²
temperature max.: 40ºC
max. working pressure: 10 bar
protective system: IP 65
electrical Connection (optionally): 230 V/50 Hz or 110-240 V 50/60 Hz 12 V DC or 24 V DC
total power: 11 W
over current protection : 10 A
