Winner - Model 3008A -Dry Dispersion Particle Size Analyzer with Automatic
Winner3008A is full automatic laser particle size analyzer with dry dispersion system. It use air as dispersion medium, and use turbulent dispersion principle with High precision feeding device, patent powder spray pump and oil-free silent gas source guaranteeing the samples to be fully dispersed. It’s fit for any dry powder chemical materials, especially the powder that takes chemical reaction with water or changes its shape in liquid. Compared to the wet laser particle size analyzer, It’s with the same accuracy and repeatability. It`s first choice for lab equipment in university and research departments.
1) Unique optical path Converging light Fourier transform light patented technology, make scattering light not be restricted to lens aperture. Use main detector and large angle auxiliary detector efficiently collect all angles of scattering light in the testing range, ensure good testing accuracy and reliability in the whole range.
2)Scientific dispersion system Turbulence dispersion patented technology and Normal shock shearing effect, make particles sufficient dispersion, Adopt wearable ceramics improve dispersion system’s working life.
3)Human-based operation mode Manual and Full automatic, very simple and easy to learn, from sample preparation to testing report just need 1 minute.
4)High precision-automatic calibration system It’s composed of precise four phase hybrid stepper motor, Its inching precision is reach to micron level, so light path is always in a good state.
5)Intelligent data analysis Analysis software collect large quantity of particle information in high speed, and inverse particle distribution by unconstrained free fitting technology, then intelligent statistics and analysis of testing data, ensure accuracy and repeatability of the output.
6) The results not only show particle distribution, the cumulative value curve and typical particle sizes( D10, D50, D90.), but also support user defined analyze result, such as any features particle diameter from D0 to D100,Cumulative percent(greater than or less than a certain particle diameter).
7) Users can design the test report output and display forms according to industry requirements.
Winner3008A Dry laser particle size analyzer used in cement, ceramics, pharmaceuticals, dyes, pigments, fillers, chemical products, catalysts, coal dust, additives, pesticides, explosives, graphite, photographic materials, fuel, metal and non-metal powder, carbonated calcium, kaolin and other powder industry, particularly for chemical reaction occurs in the liquid, the shape change and the loss of such herbs, magnetic materials and relatively wide distribution and larger particles powder industry more unique applicability and practicality.
