Mount Sopris - Model QL40-IND -Dual Focused Induction Probe

SHARE

The QL40-IND Dual Focused Induction probe provides two simultaneous conductivity logs, corresponding to “Medium” and “Deep” radii of investigation into the borehole. The two depths of penetration are useful in porous, permeable formations where displacement of formation fluids by drilling mud creates an invasion zone with different electrical properties. High stability and exceptionally wide dynamic range allow the user to carry out precise measurements of conductivity in formations with sand-clay layers and mineralized, water-soaked sands. In contrast to electrical tools, this induction tool can be used in dry and non-metallic cased holes. The QL40-IND tool is stackable within the Quick Link (QL) product line or it can be run as a standalone tool.

Most popular related searches
induced polarization
mining exploration
drilling mud
well monitoring
borehole
well water
water salinity monitoring
water well monitor
water well monitoring
borehole depth
  • Indicator of permeable zones and porosity
  • Formation water salinity
  • Long term well monitoring
  • Ore Identification and quality correlation
  • Indication of Hydrocarbons

Borehole Fluid

  • Water
  • Mud
  • Dry

Casing

  • Uncased
  • PVC Borehole
  • Steel

Centralization

  • Required
  • Not Necessary
  • Two depths of investigation for detailed formation characterization
  • More temperature stabilization than other tools on the market
  • Easy to calibrate for specific borehole conductivity ranges
  • Operates on any standard wireline (Mono, 4, 7 conductor, or Coax)
  • Slim, 45 mm diameter. One-person operation.
  • Can be combined with other logging tools of the QL product line or operated as a standalone tool.
  • Intercoil Spacing: 50 cm and 80 cm
  • Operating Frequency: ~100 kHz
  • Accuracy: < 3% F.S.
  • Stability: < 0.5 mS/ 10 ºC
  • Conductivity Range: 1-3000 mS/m
  • QL40IND + QL40GR (Gamma): Lithology tool in Dry and Non-Magnetic cased holes
  • QL40IND + QL40IP (Induced Polarization) : Hydrothermal Vein location, Graphite location
  • QL40IND + QL40IP (Induced Polarization) + QL40GR (Gamma): Uranium Exploration
  • QL40IND + QL40IP (Induced Polarization) + QL40MGS (Mag. Sus.): Mining Exploration Tool, Mineral and Ore body Identification
