Cruma - Model Class 1 -Ductless Filtration Fume Hoods
The ductless filtration fume hoods included in the Plug&Play range are ideal for eliminating contaminating gas and/or solid particles/aerosols from the work space simply and efficiently. Safe, efficient and cost-effective, these protect both the user and the environment. The range is already assembled on delivery (just unpack, install the filters and plug in) and all the models are equipped with the new filtration system, developed and patented by Cruma (Invention Patent), to retain the contaminating gas and fumes generated on the inside thus constantly renewing the air inside the laboratory.
The main advantages offered are:
Personnel Safety and Environmental Protection
Apart from completely protecting the person handling the material inside the cabinet, the chemical toxins produced are not released to the outside but remain inside the cabinet thanks to the filtration system formed by a variety of activated carbon filters.
Flexible
These can be used in areas where it is difficult to extract contaminated air, such as the lower floors of buildings, and they can be placed in different locations, which it means that they can be easily relocated if needed.
Economic Savings and Easy to Set-Up
No expensive works are necessary to install conduits to extract the gas to the outside which means there are no additional costs and no need to interrupt a laboratory working at full capacity.
Energy Savings
Unlike traditional extraction hoods, our fume hoods do not use the air conditioning equipment inside the laboratory, which substantially reduces energy costs. The aspirated air is not expelled outside but recirculated back into the laboratory free from contaminating substances.
Yes, they all fit and are standard.
More information on the new LCD display
- New size 127x34mm display
- Air speed continuously monitored
- Type of filter installed, working hours, expiration date and next revision date
- Open door warning through electronic photocell
- Countdown timer
- Clock and calendar
New features and components
- Initial air flow cycle adequacy and final purge cycle
- Fault LED
- Control of air flow through Microprocessor
- Activated carbon filters with electronic chip
- Internal temperature sensor
- LED illumination
New alarms and scheduled warnings
- Open door warning
- Open door in off mode warning
- 60h of filter use warning
- Next validation warning
- Few hours of filter life warning
- Countdown timer warning
- Expired filter alarm (by hours)
- Expired filter alarm (by date)
- Temperature alarm
- Equipment without filter alarm
- Low barrier alarm
Handling
But we’re sure you’ll find more.
General chemistry involving small volumes of reagents or chemical compounds at ambient/moderate temperature in all types of laboratories:
- Research laboratories
- Quality control laboratories
- Clinical and hospital laboratories
- University and school laboratories
- …In general, in any kind of laboratory.
The fume hoods in the Plug&Play range were designed to ensure that practicaly no handling operations are necessary once these have been received: all you have to do is take them out of their fantastic packaging, place them in the desired spot, install the filters, plug them into the mains and get to work. As simple as their name suggests: plug in and play.
All of the Plug&Play fume hoods use the new filtration system, developed and patented by Cruma (Invention Patent), which protects the operator by retaining the contaminating gas, fumes and particles generated inside, constantly renewing the air inside the laboratory and avoiding leaks that may contaminate the environment.
