Elite - Model TSH12 -Single-Zone Tube Furnace

SHARE

The TSH12 furnace is a bench mounted tube furnace ideal for most general laboratory thermal processing applications. Special arrangement via resistance wire wound onto a ceramic worktube which is an integral part of the furnace gives optimum temperature uniformity throughout the furnace.  Vertical versions are available which have a separate temperature console.

Most popular related searches
single-zone tube furnace
tube furnace
furnace
digital temperature controller
thermocouple
laboratory furnace
multi-gas
process gas
  • The furnace design incorporates an integral elemental tube.
  • Protective outer mesh covers for improved operator safety.
  • Low thermal mass insulation is used throughout for rapid response rates and maximum efficiency and stability.
  • For aggressive processes, a separate work tube is recommended to minimise the risk of contaminating the elemental work tube.
  • A rugged metal sheathed control thermocouple is protected from accidental damage and allows full use of work tube bore.
  • Horizontal models are supplied as standard with controls in the base.
  • `N` Type thermocouple is used in these furnaces.
  • High end Microprocessor PID controller.
  • Work tubes of various materials, lengths and diameters for use in the furnace
  • The work tubes are available for containment of atmosphere or protection against process contaminants.
  • A variety of end seals for work tubes to allow processing under vacuum or gas atmospheres.
  • Multi segment, multi program storage controller
  • Over temperature protection controller.
