Elite Thermal Systems Ltd. products

The BAF 7 air re-circulating furnaces provide good temperature uniformity and rapid thermal transfer to the load at lower temperatures, suitable for low temperature applications such as annealing, stress relieving, tempering and normalising and offers a choice of chamber capacities ranging from 15 to 45 litre. Applications include annealing, stress relieving, tempering and normalising.

BCF 11 Economy Chamber furnace is suitable for light-duty general laboratory work providing satisfactory performance for many firing applications and is available in various capacities ranging from 3 litres to 45 litres.

BCF12 and BCF13 General purpose chamber furnace is designed for General purpose laboratory applications and providing satisfactory performance for many firing applications and is available in various capacities ranging from 3 litres to 45 litres.

The BSFA furnace is designed for ashing applications, its design makes it ideal for treating heavier loads, and the processing of material that could contaminate floor mounted heating elements through spillage. Ideal for ashing foods, plastics, coal & other hydrocarbon materials.

The TSH12 furnace is a bench mounted tube furnace ideal for most general laboratory thermal processing applications. Special arrangement via resistance wire wound onto a ceramic worktube which is an integral part of the furnace gives optimum temperature uniformity throughout the furnace.  Vertical versions are available which have a separate temperature console.

The TMH12 furnace is a bench mounted tube furnace ideal for most general laboratory thermal processing applications. High grade resistance wire elements wound onto a ceramic worktube which is an integral part of the furnace. Vertical versions are available which have a separate temperature console.

The TSHH split tube furnace is designed to meet the needs of `in-line` thermal processes, and for when rapid cooling is required. Free radiating high grade resistance wire elements supported on ceramic tubes. Vertical versions are available which have a separate console.

The TSHVC12 is a Horizontal tube furnace with integral vacuum equipment for low vacuum use with an ultimate vacuum level 10 ¯5 mbar nominal. Heating is via a resistance wire element wound onto the ceramic worktube which is an integral part of the furnace

The TSHVC15 is a Horizontal tube furnace with integral vacuum equipment for low vacuum use with an ultimate vacuum level 10 ¯5 mbar nominal. Top grade silicon carbide rods mounted parallel with and equispaced around the furnace tube.
